Tractor · 2004Unverified
New Holland TK80
New Holland TK80 — TK-A Series · 77 hp. Reference specifications; pending source verification.
The New Holland TK80 is a tractor with a rated output of 77 hp, positioning it centrally within its class in terms of power. This model was manufactured from 2004 to 2009 and features a 4-cylinder diesel liquid-cooled engine. The tractor's transmission includes an 8-speed gearbox and a tracked undercarriage. Its listed weight ranges from 8460 to 8570 pounds, with an intended application of up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
77 hp
Weight
8460 to 8570 pounds
Catalogue coverage
Variants represented
2
Richest spec table
47 rows
Recorded power
77 hp
Recorded weight
3837 kg
Transmissions
8-speed constant mesh
Production years
2004-2009
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
ManufacturerNew HollandReference
Agricultural Crawler tractorReference
DrivecrawlerReference
Two-post mid-mount folding ROPS.Reference
Engine
Iveco 3.9L 4-cyl dieselReference
Fuel tank121.1 LReference
Engine (gross)57.4 kWReference
IvecoReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.9 LReference
Bore/Stroke104 x 115 mmReference
Power (gross)57.4 kWReference
Rated RPM2500Reference
Starter volts12Reference
Transmission
8-speed constant meshReference
Typeconstant meshReference
Gears8 forward and reverseReference
Clutch292mm dry discReference
PTO & Hydraulics
PTO (claimed)49.2 kWReference
Typeopen centerReference
Pressure190.0 barReference
Valves3Reference
Pump flow45.0 lpmReference
Steering flow18.9 lpmReference
Rear TypeII/IReference
Rear lift1848 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase158 cmReference
Weight8460 to 8570 poundsReference
12.2-inch tracksReference
Length336 cmReference
TK80A Width140 cmReference
TK80MA Width169 cmReference
Height (ROPS)234 cmReference
TK80A Weight3837 kgReference
TK80MA Weight3887 kgReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps45Reference
Battery CCA800Reference
Battery volts12Reference
New Holland TK80 Tracks
Width30 cmReference
Width35 cmReference
Width40 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
