Tractor · 2000Unverified

New Holland TK85

Name: New Holland TK85
Brand: New Holland

New Holland TK85 — TK Series · 65 hp. Reference specifications; pending source verification.

The New Holland TK85 is a tractor with a rated power of 65 hp, a mid-range figure for its class. It was manufactured from 2000 to 2004. The TK85 features a 4-cylinder diesel liquid-cooled engine, paired with a tracked undercarriage and an 8-speed gearbox. Its operating weight ranges from 8570 to 8900 pounds.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

65 hp

Weight

8570 to 8900 pounds

Catalogue coverage

Variants represented

Richest spec table

51 rows

Recorded power

65 hp

Recorded weight

3887 kg

Transmissions

8-speed constant mesh

Production years

2000-2004

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerNew HollandReference

Agricultural Crawler tractorReference

DrivecrawlerReference

Two-post mid-mount folding ROPS.Reference

Variants

TK85Mwide trackReference

Engine

Iveco 3.9L 4-cyl dieselReference

Fuel tank120.0 LReference

Engine59.7 kWReference

Iveco 8045.05Reference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement3.9 LReference

Bore/Stroke104 x 115 mmReference

Power59.7 kWReference

Rated RPM2500Reference

Starter volts12Reference

Transmission

8-speed constant meshReference

Typeconstant meshReference

Gears8 forward and reverseReference

Clutch292mm dry discReference

PTO & Hydraulics

PTO (claimed)48.5 kWReference

Rear valves3 to 5Reference

Pump flow45.4 lpmReference

Steering flow18.9 lpmReference

Rear TypeII/IReference

ControlTop-link draft sensing.Reference

Rear lift (at 24"/610mm)1849 kgReference

Rear PTOindependentReference

Clutch280mm dry discReference

Rear PTO Type540/1000Reference

Engine RPM540@2199Reference

Engine RPM1000@2381Reference

Dimensions

Wheelbase158 cmReference

Weight8570 to 8900 poundsReference

12.2-inch tracksReference

Length362 cmReference

TK85 Width140 cmReference

TK85M Width169 cmReference

Height (hood)130 cmReference

Height (ROPS)234 cmReference

TK85 Weight3887 kgReference

TK85M Weight4037 kgReference

TK85 Gauge109 cmReference

TK85M Gauge130 cmReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps45Reference

Battery volts12Reference

New Holland TK85 Tracks

Width30 cmReference

Width40 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
