New Holland TL100A
New Holland TL100A — TL-A Series · 98 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
98 hp
Max power
44.0 kW
Weight
6834 to 8905 pounds
Hover a source tag to verify
Overview
ManufacturerNew HollandReference
Utility tractorReference
Built in Jesi, ItalyReference
The New Holland TL100A is available in standard and deluxe configurations. The deluxe model features the 24x24 power shift, air-ride seat, electro-hydraulic PTO, and flexible link ends on the three-point hitch.Reference
Two- or four-wheel driveReference
Differential lockmechanical rearReference
Differential lockelectro-hydraulic rearReference
Hydrostatic power brakesReference
ROPS. Cab optional.Reference
Engine
CNH Diesel 4.5L 4-cyl dieselReference
Fuel tank126.8 LReference
Engine (gross)73.1 kWReference
Drawbar (tested)44.0 kWReference
CNH DieselReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.5 LReference
Bore/Stroke104 x 132 mmReference
Power (gross)73.1 kWReference
Air cleanerdual dry elementReference
Compression17.5:1Reference
Rated RPM2500Reference
Torque RPM1400Reference
StarterelectricReference
Starter volts12Reference
Oil capacity9.8 LReference
Coolant capacity12.1 LReference
Coolant capacity14.0 LReference
Power at rated engine speed65.0 kWReference
Max power44.0 kWReference
Transmission
12-speed mechanical shuttleReference
24-speed power shuttleReference
TransmissionSynchro CommandReference
Typemechanical shuttleReference
Gears12 forward and reverseReference
Clutchdry discReference
TransmissionDual CommandReference
Typepower shuttleReference
Gears24 forward and reverseReference
Clutchwet discReference
PTO & Hydraulics
PTO (claimed)63.4 kWReference
PTO (tested)65.0 kWReference
Typeopen centerReference
Valves1 to 3Reference
Pump flow54.9 lpmReference
Total flow75.7 lpmReference
Steering flow20.8 lpmReference
Rear TypeIIReference
Controlmechanical lower-link draft controlReference
Rear lift (at ends)0 kgReference
Rear lift (at ends)0 kgReference
Rear lift (at 24"/610mm)2605 kgReference
Rear PTOindependentReference
Standard Clutch12-inch cerametallic dry discReference
Deluxe Clutchwet discsReference
Rear PTO Type540/1000Reference
Power at rated PTO speed65.6 kWReference
Dimensions
Weight6834 to 8905 poundsReference
Ag rearhydraulic wet discReference
Width184 cmReference
Width201 cmReference
Front tread142 to 213 cmReference
Rear tread152 to 213 cmReference
Shipping3099 kgReference
Shipping3299 kgReference
Shipping3395 kgReference
Shipping3599 kgReference
Operating3869 kgReference
Operating4039 kgReference
Ballasted4944 kgReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps120Reference
Battery CCA960Reference
Battery volts12Reference
New Holland TL100A Height
ROPS265 cmReference
ROPS213 cmReference
Cab260 cmReference
Exhaust298 cmReference
Test results
Diesel 12-speed 4WDOctober 2004 - November 2004, Link: OCED Tractor Test 2247 fileReference
PTO performanceReference
Fuel use21.2 l/hourReference
Fuel use20.8 l/hourReference
Drawbar performanceReference
Fuel use19.3 l/hourReference
Gear 2M used for power test.Reference
Max pull4701 kgReference
Gear 1L used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
