Tractor · 1999Unverified

New Holland TL70

Name: New Holland TL70
Brand: New Holland

New Holland TL70 — TL Series · 59 hp. Reference specifications; pending source verification.

The New Holland TL70 is a tractor model with a rated power output of 59 hp, positioning it at the lighter end of its class. This model was manufactured from 1999 to 2001. It is equipped with a 4-cylinder diesel liquid-cooled engine, paired with a four-wheel drive system and a powershift transmission. The operating weight of the TL70 ranges from 5952 to 8245 pounds.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

59 hp

Max power

27.2 kW

Weight

5952 to 8245 pounds

Catalogue coverage

Variants represented

Richest spec table

99 rows

Recorded power

59 hp

Transmissions

12-speed partially synchronized

Production years

1999-2001

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerNew HollandReference

Utility tractorReference

Built in Jesi, ItalyReference

Two- or four-wheel driveReference

Final drivesplanetaryReference

Differential lockmechanical rearReference

Power steeringReference

Differential hydraulic wet disc brakesReference

Two-post folding ROPS. Cab optional with air-conditioning.Reference

Engine

Iveco 3.6L 4-cyl dieselReference

Fuel tank109.8 LReference

Engine48.5 kWReference

Drawbar (tested)27.2 kWReference

Iveco 8045Reference

dieselReference

4-cylinderReference

liquid-cooled inlineReference

Displacement3.6 LReference

Bore/Stroke100 x 115 mmReference

Power48.5 kWReference

Air cleanerdual paper elementsReference

Compression16.5:1Reference

Rated RPM2500Reference

Starter volts12Reference

Power at rated engine speed43.9 kWReference

Max power27.2 kWReference

Transmission

12-speed partially synchronizedReference

12-speed mechnical shuttleReference

24-speed two-speed power shiftReference

24-speed power shuttleReference

Typepartially synchronizedReference

Gears12 forward and 4 reverseReference

Clutch304.8mm dry discReference

Four synchronized gears in three ranges, plus reverse. Tractor must be stopped, and clutch used, to shift range.Reference

TransmissionSynchro CommandReference

Typemechnical shuttleReference

Gears12 forward and reverseReference

Available with creeper ranges providing 20 forward and 8 reverse speeds.Reference

Typetwo-speed power shiftReference

Gears24 forward and 12 reverseReference

Typepower shuttleReference

Gears24 forward and reverseReference

Four synchronized gears in three ranges with two-speed push-button power shift and power shuttle.Reference

PTO & Hydraulics

PTO (claimed)41.8 kWReference

PTO (tested)43.9 kWReference

Typeopen centerReference

Valves2 or 3Reference

Pump flow54.9 lpmReference

Total flow75.7 lpmReference

Steering flow20.8 lpmReference

Rear TypeIIReference

Rear lift2971 kgReference

Rear PTOindependentReference

ClutchmanualReference

Clutchelectro-hydraulic wet discReference

Rear PTO Type540/1000 (1.375)Reference

Engine RPM540@2199Reference

Engine RPM1000@2381Reference

Power at rated PTO speed42.1 kWReference

Dimensions

2WD Wheelbase234 cmReference

4WD Wheelbase231 cmReference

Weight5952 to 8245 poundsReference

Front tire10.00-16Reference

2WD Rear tire13.6R-36Reference

2WD Standard tires (ag)Front: 10.00-16. Rear: 13.6R-36Reference

4WD Standard tires (ag)Front: 12.4R-24. Rear: 13.6R-36Reference

2WD Length391 cmReference

4WD Length406 cmReference

ROPS Width235 cmReference

Cab Width201 cmReference

Height (ROPS)267 cmReference

Height (Folded ROPS)240 cmReference

Height (cab)278 cmReference

Clearance (front axle)29 cmReference

Front tread140 to 216 cmReference

Rear tread141 to 220 cmReference

2WD ROPS Shipping2699 kgReference

4WD ROPS Shipping3089 kgReference

2WD Cab Shipping2899 kgReference

4WD Cab Shipping3200 kgReference

2WD Operating3474 kgReference

4WD Operating3739 kgReference

Ballasted4490 kgReference

New Holland TL70 attachments

front-end loaderReference

TL70 Serial Numbers

Location:Serial number stamped on the front axle support under the tractor hood.Reference

Electrical

GroundnegativeReference

Battery volts12Reference

Attachment overview

New Holland 52LA loaderReference

New Holland 52LA MSL loaderReference

Test results

Diesel 24-speed 4WDApril 1999 - December 1999, Link: OCED Tractor Test 1913 fileReference

PTO performanceReference

Fuel use14.0 l/hourReference

Fuel use12.9 l/hourReference

Drawbar performanceReference

Fuel use11.4 l/hourReference

Gear 3M Lo used for power test.Reference

Max pull4111 kgReference

Gear 3S Lo used for pull test.Reference

Speeds

With 16.9-30 rear tires.Reference
