Tractor · 2002Unverified
New Holland TL85E Exitus
New Holland TL85E Exitus — Model year 2002-20062002-20122013-2023 · 85 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
85 hp
Weight
6945 to 8686 pounds
Hover a source tag to verify
Overview
ManufacturerNew HollandReference
Built in Curitiba, BrazilReference
Four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Two-post ROPS.Reference
Engine
Iveco 3.9L 4-cyl dieselReference
Fuel tank98.8 LReference
Engine63.4 kWReference
IvecoReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.9 LReference
Bore/Stroke104 x 115 mmReference
Power63.4 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed shuttleReference
TypeshuttleReference
Gears12 forward and reverseReference
Clutchmechanical cerametallic discReference
Four gears (1-4) in four ranges (I-IV) with shuttle shift.Reference
PTO & Hydraulics
Typeopen centerReference
Pump flow44.5 lpmReference
Rear TypeIIReference
Rear lift (at 24"/610mm)3339 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Dimensions
Weight6945 to 8686 poundsReference
Front tire7.5x16Reference
2WD Rear tire18.4x30Reference
2WD Standard tires (ag)Front: 7.5x16. Rear: 18.4x30Reference
4WD Standard tires (ag)Front: 12.4x24. Rear: 18.4x30Reference
2WD Shipping weight3150 kgReference
4WD Shipping weight3939 kgReference
Electrical
Charging systemalternatorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
