Tractor · 2004Unverified

New Holland TN75FA

Name: New Holland TN75FA
Brand: New Holland

New Holland TN75FA — TN-A Series · 74 hp. Reference specifications; pending source verification.

The New Holland TN75FA is a tractor with a rated power of 74 hp, a mid-range figure for its class. It was manufactured between 2004 and 2008. The tractor is powered by a 4-cylinder diesel liquid-cooled engine, coupled with mechanical front-wheel drive and a hydrostatic transmission. Its operating weight is listed at 2800 kg, making it suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

74 hp

Weight

2800 kg

Catalogue coverage

Variants represented

Richest spec table

53 rows

Recorded power

74 hp

Recorded weight

2800 kg

Transmissions

16-speed synchronized mechanical shuttle

Production years

2004-2008

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerNew HollandReference

Utility tractorReference

Built in Jesi, ItalyReference

Drive4x2 2WDReference

Drive4x4 MFWD 4WD (optional)Reference

Steeringhydrostatic powerReference

ROPS. Optional cab. Optional Blue Cab with A/C and filtration.Reference

Variants

TN75AROPSReference

TN75DAcabReference

TN75SASuperSteerReference

TN75FAnarrow/orchardReference

Engine

Iveco 3.9L 4-cyl dieselReference

Engine (gross)55.2 kWReference

IvecoReference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement3.9 LReference

EmissionsTier 2Reference

Power (gross)55.2 kWReference

Rated RPM2300Reference

StarterelectricReference

Starter volts12Reference

Transmission

16-speed synchronized mechanical shuttleReference

Typesynchronized mechanical shuttleReference

Gears16 forward and reverseReference

PTO & Hydraulics

Typeopen centerReference

Valves2 or 3Reference

Pump flow46.9 lpmReference

Steering flow27.3 lpmReference

Rear TypeI/IN/IIReference

Rear lift (at 24"/610mm)2310 kgReference

Front HitchoptionalReference

Front lift (at 24"/610mm)1359 kgReference

Rear PTOindependentReference

Rear PTO Type540/1000Reference

Rear PTO Type540/750/1000 (optional)Reference

Front PTOindependent (optional)Reference

Front PTO Type1000Reference

Dimensions

Wheelbase223 cmReference

Wheelbase243 cmReference

Weight2800 kgReference

Length400 cmReference

Width140 cmReference

Height (cab)225 cmReference

Shipping weight2800 kgReference

Front tread122 to 162 cmReference

Rear tread114 to 147 cmReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps85Reference

Battery CCA800Reference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
