Tractor · 2004Unverified
New Holland TN95DA
New Holland TN95DA — TN-A Series · 90 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
90 hp
Max power
62.4 kW
Weight
6559 to 6835 pounds
Hover a source tag to verify
Overview
ManufacturerNew HollandReference
Utility tractorReference
Built in Jesi, ItalyReference
Four-wheel driveReference
Differential lockmechanical rearReference
Steeringhydrostatic powerReference
Differential wet disc brakesReference
Cab standard.Reference
Variants
TN95AROPSReference
TN95DAcabReference
TN95FAnarrow/orchardReference
Engine
Iveco 4.5L 4-cyl dieselReference
Fuel tank88.9 LReference
Engine (gross)67.1 kWReference
Drawbar (tested)55.2 kWReference
IvecoReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.5 LReference
Bore/Stroke104 x 132 mmReference
EmissionsTier 2Reference
Power (gross)67.1 kWReference
Fuel use19.7 l/hourReference
Air cleanerdual paper elementsReference
Compression17.5:1Reference
Rated RPM2300Reference
Torque364.8 NmReference
Torque RPM1400Reference
StarterelectricReference
Starter volts12Reference
Max power62.4 kWReference
Power at rated engine speed62.2 kWReference
Max power55.2 kWReference
Transmission
12-speed partially synchronized with power shuttleReference
TransmissionSynchro CommandReference
Typepartially synchronized with power shuttleReference
Gears12 forward and reverseReference
Clutchsix 113mm wet organic discsReference
Left-hand clutchless power shuttleReference
PTO & Hydraulics
PTO (claimed)57.4 kWReference
PTO (tested)62.4 kWReference
Typeopen centerReference
Pressure190.0 barReference
Valves1 to 4Reference
Pump flow56.8 lpmReference
Steering flow35.6 lpmReference
Rear TypeII/IReference
Rear lift (at 24"/610mm)1796 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Power at rated PTO speed62.0 kWReference
Dimensions
Wheelbase218 cmReference
Weight6559 to 6835 poundsReference
Length405 cmReference
Width170 cmReference
Height (cab)230 cmReference
Shipping2975 kgReference
Operating3100 kgReference
Ballasted3665 kgReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps85Reference
Battery CCA730Reference
Battery volts12Reference
Test results
Diesel 12-speed 4WDSeptember 1 - October 1, 2005Link: OCED Tractor Test 2346 fileReference
PTO performanceReference
Fuel use19.3 l/hourReference
Fuel use19.7 l/hourReference
Drawbar performanceReference
Gear 1 Hi used for power test.Reference
Max pull3093 kgReference
Gear 2M Hi used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
