Tractor · 2012Unverified
New Holland TS6.120 High-Clearance
New Holland TS6.120 High-Clearance — TS6 Series · 118 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
118 hp
Weight
8789 to 9528 pounds
Hover a source tag to verify
Overview
ManufacturerNew HollandReference
High-Clearance tractorReference
Original price$66,831 (2014 Mech Shuttle ROPS )Reference
Original price$79,893 (2014 DualPower Cab )Reference
Four-wheel driveReference
Two-post foldable ROPS. Cab optional with air-conditioning.Reference
Variants
TS6.120row-cropReference
TS6.120HChigh-cropReference
Engine
FPT 4.5L 4-cyl dieselReference
Engine (gross)88.0 kWReference
FPTReference
turbocharged intercooled dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.5 LReference
Bore/Stroke104 x 132 mmReference
EmissionsTier IIIReference
Power (gross)88.0 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed mechanical shuttleReference
12-speed power shuttleReference
24-speedReference
Typemechanical shuttleReference
Gears12 forward and reverseReference
Clutchdry discReference
Typepower shuttleReference
Clutchwet discReference
TransmissionDualPowerReference
Gears24 forward and reverseReference
PTO & Hydraulics
PTO (claimed)71.6 kWReference
Pump flow49.2 lpmReference
Pump flow83.3 lpmReference
Steering flow34.1 lpmReference
Rear TypeIIReference
Rear lift (at 24"/610mm)1632 kgReference
Rear lift (at 24"/610mm)2449 kgReference
Rear lift (at 24"/610mm)3265 kgReference
Rear PTOindependentReference
Clutchwet discReference
Rear PTO Type540/1000Reference
Dimensions
Weight8789 to 9528 poundsReference
Length401 cmReference
Height (ROPS)325 cmReference
Height (cab)309 cmReference
Shipping weight3986 kgReference
Shipping weight4321 kgReference
Clearance (front axle)64 cmReference
Clearance (drawbar)75 cmReference
Flange rear axleReference
Front tread182 to 213 cmReference
Rear tread182 to 213 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps120Reference
Battery CCA950Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
