Tractor · 2002Unverified

New Holland TT55

Name: New Holland TT55
Brand: New Holland

New Holland TT55 — TT Series · 47 hp. Reference specifications; pending source verification.

The New Holland TT55 is a tractor with a rated power output of approximately 47 hp, placing it in the lighter category of its class. Produced from 2002 to 2008, this model features a 3-cylinder diesel liquid-cooled engine, paired with four-wheel drive and an 8-speed gearbox. Its listed operating weight is 2220 kg, and it is suited for operations on up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

47 hp

Weight

2220 kg

Catalogue coverage

Variants represented

Richest spec table

61 rows

Recorded power

47 hp

Recorded weight

2220 kg

Transmissions

8-speed constant mesh

Production years

2002-2008

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerNew HollandReference

Utility tractorReference

Built in IndiaReference

Two- or four-wheel driveReference

Final drivesspur gearReference

SteeringmanualReference

Steeringpower (4WD)Reference

Wet disc brakesReference

Two-post ROPS.Reference

Engine

Iveco 2.9L 3-cyl dieselReference

Fuel tank88.9 LReference

Engine41.1 kWReference

IvecoReference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement2.9 LReference

Bore/Stroke104 x 115 mmReference

Power41.1 kWReference

Fuel systemdirect injectionReference

Air cleaneroil bathReference

Air cleanerdryReference

Rated RPM2500Reference

Torque184.6 NmReference

Torque RPM1500Reference

Starter volts12Reference

Transmission

8-speed constant meshReference

Typeconstant meshReference

Gears8 forward and 2 reverseReference

PTO & Hydraulics

PTO (claimed)35.0 kWReference

Typeopen centerReference

Pump flow32.6 lpmReference

Total flow59.0 lpmReference

Steering flow26.5 lpmReference

Rear TypeII/IReference

Controlposition and draft controlReference

Rear lift1525 kgReference

Rear PTOindependentReference

Rear PTO Type540Reference

Engine RPM540@1967Reference

Dimensions

2WD Wheelbase204 cmReference

4WD Wheelbase200 cmReference

Weight2220 kgReference

Front tire7.50-16Reference

Rear tire16.9-28Reference

Ag front7.50-16 (2WD)Reference

Ag front9.5-24 (4WD)Reference

Ag rear16.9-28Reference

Ag front6.00-16.8Reference

Ag rear13.6-28Reference

Ag rear14.9-28Reference

Height220 cmReference

Ground clearance50 cmReference

Ground clearance38 cmReference

New Holland TT55 attachments

front-end loaderReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps23Reference

Battery volts12Reference

Battery AH88Reference

Speeds

With 16.9x28 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
