Tractor · 2004Unverified

New Holland TV145

Name: New Holland TV145
Brand: New Holland

New Holland TV145 · 103 hp. Reference specifications; pending source verification.

The New Holland TV145 is a tractor with a rated output of 103 hp, placing it in the middle of its class in terms of power. It was manufactured from 2004 to 2008. The tractor is equipped with a 6-cylinder turbocharged diesel liquid-cooled engine, which drives the four-wheel drive via a hydrostatic transmission. Its listed weight is 6674 kg, making it suitable for tasks covering approximately 200–800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

103 hp

Max power

83.4 kW

Weight

6674 kg

Catalogue coverage

Variants represented

Richest spec table

61 rows

Recorded power

103 hp

Recorded weight

6674 kg

Transmissions

hydrostatic

Production years

2004-2008

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerNew HollandReference

Four-wheel driveReference

Steeringhydrostatic powerReference

Hydraulic wet disc brakesReference

Cab standardReference

Engine

New Holland 7.5L 6-cyl dieselReference

Engine108.1 kWReference

Drawbar (tested)60.6 kWReference

New HollandReference

turbocharged dieselReference

6-cylinderReference

liquid-cooledReference

Displacement7.5 LReference

Power108.1 kWReference

Rated RPM2200Reference

Starter volts12Reference

Oil capacity17.0 LReference

Coolant capacity27.4 LReference

Max power83.4 kWReference

Power at rated engine speed77.0 kWReference

Max power60.6 kWReference

Transmission

hydrostaticReference

TypehydrostaticReference

Gearsinfinite forward and reverse (3-range)Reference

PTO & Hydraulics

PTO (claimed)78.3 kWReference

PTO (tested)83.4 kWReference

Hydraulic system39.7 LReference

Typeclosed center load sensingReference

Capacity39.7 LReference

Pump flow113.6 lpmReference

Rear Type2Reference

Rear lift3946 kgReference

Front Hitch2Reference

Front lift1814 kgReference

Rear PTO Type540/1000Reference

Front PTO Type540/1000Reference

Power at rated PTO speed81.3 kWReference

Capacities

Fuel208.2 LReference

Dimensions

Wheelbase299 cmReference

Weight6674 kgReference

Length466 cmReference

Width196 cmReference

Height309 cmReference

Operating weight6674 kgReference

TV145 Serial Numbers

2004RVS022001Reference

2005RVS022801Reference

2006RVS023601Reference

2007RVS055001Reference

2008RVS055348Reference

FAQ: How to read a serial number table.Reference

Electrical

GroundnegativeReference

Charging amps120Reference

Battery CCA950Reference

Test results

Diesel hydrostatic 4WDNovember 1 - 30, 1999Link: OCED Tractor Test 1886 fileReference

PTO performanceReference

Fuel use26.9 l/hourReference

Fuel use29.1 l/hourReference

Fuel use26.1 l/hourReference

Drawbar performanceReference

Fuel use29.9 l/hourReference

Max pull4994 kgReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
