Tractor · 2015Unverified

New Holland Workmaster 37

Name: New Holland Workmaster 37
Brand: New Holland

New Holland Workmaster 37 — Workmaster Series · 30 hp. Reference specifications; pending source verification.

The New Holland Workmaster 37 is a tractor with a rated power of 30 hp, positioning it at the lighter end of its class. It was manufactured between 2015 and 2016. The tractor features a 3-cylinder turbocharged diesel liquid-cooled engine, paired with four-wheel drive and a hydrostatic transmission. Its listed operating weight is 1391 kg, suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

30 hp

Max power

36.2 hp

Weight

1391 kg

Catalogue coverage

Variants represented

Richest spec table

91 rows

Recorded power

30 hp

Recorded weight

1391 kg

Transmissions

12-speed synchronized shuttle

Production years

2015-2016

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerNew Holland (a part of CNH)Reference

Compact Utility tractorReference

Four-wheel driveReference

Final drivesinboard planetaryReference

Power steeringReference

Wet disc brakesReference

Two-post folding ROPS.Reference

Engine

Shibaura 1.5L 3-cyl dieselReference

Fuel tank28.0 LReference

Engine27.0 kWReference

Shibaura N843T-F-27Reference

turbocharged dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.5 LReference

Bore/Stroke84 x 90 mmReference

EmissionsTier IVReference

Emission controlexhaust gas recirculation with diesel particulate filterReference

Power27.0 kWReference

Fuel systemelectronic indirect injectionReference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Fuel TypeDieselReference

No of Cylinders3 CylinderReference

Rated engine speed2,600 RPMReference

Bore and stroke3.307x3.543 inchesReference

Cooling systemliquid-cooledReference

Transmission

12-speed synchronized shuttleReference

hydrostaticReference

Typesynchronized shuttleReference

Gears12 forward and reverseReference

Four gears in three ranges with mechanical shuttleReference

TypehydrostaticReference

Gearsinfinite forward and reverse (3-range)Reference

Transmission TypeHSTReference

Wheel Drive4WDReference

Rear Axle Drive Typeinboard planetaryReference

PTO & Hydraulics

Gear PTO (claimed)22.1 kWReference

Hydro PTO (claimed)21.0 kWReference

Typeopen centerReference

Valves1 or 2Reference

Pump flow31.0 lpmReference

Rear TypeIReference

Controlposition controlReference

Rear lift (at ends)820 kgReference

Rear lift (at 24"/610mm)650 kgReference

Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Dimensions

Wheelbase171 cmReference

Weight1391 kgReference

Front tire7x14Reference

Rear tire11.2x24Reference

Standard tires (ag)Front: 7x14. Rear: 11.2x24Reference

Lawn/turf front25x8.50-14Reference

Lawn/turf rear41x14.00-20Reference

Industrial front25x8.5-14Reference

Industrial rear43x16.00-20Reference

Length307 cmReference

Width168 cmReference

Height (ROPS)222 cmReference

Flange rear axleReference

New Holland Workmaster 37 attachments

front-end loaderReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps85Reference

Battery volts12Reference

General

Make & ModelNew Holland (a part of CNH)Reference

Cruise controlAvailableReference

SCV controlJoystickReference

Rear Axle TypeFlangeReference

Rollover protective structureTwo-post folding ROPS.Reference

Capacities

Capacity91.3 ciReference

Power

Max Power36.2 hpReference

PTO

PTO Power29.6 hpReference

Rear PTO PowerAvailableReference

Rear PTO RPM540 RPMReference

Steering & brakes

Brakeswet discReference

Steering typepowerReference

Hydraulics

Hydraulics Typeopen centerReference

Remote Valves1 or 2 ValvesReference

Rear Hitch category (SAE designation)Category IReference

Rear Hitch maximum lift capacity820.1 kgReference

Rear Hitch Sensing Typeposition controlReference

Dimensions & weight

Height Over ROPS222.8 cmReference

Overall Length307.3 cmReference

Overall Width168.9 cmReference

Overall weight1,391.2 kgReference

Wheels & tyres

Rear Wheel Type11.2x24Reference

Front Wheel Type7x14Reference

Operator station

Cab AvailabilityAvailableReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
