New Holland Workmaster 40C
New Holland Workmaster 40C — Workmaster Series · 40 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
40 hp
Hover a source tag to verify
Overview
ManufacturerNew Holland (a part of CNH)Reference
Compact Utility tractorReference
Four-wheel driveReference
Power steeringReference
Two-post folding ROPS.Reference
Variants
Farmall 40Asimilar CaseIH modelReference
Engine
LS Mtron 1.9L 3-cyl dieselReference
Fuel tank47.7 LReference
Engine29.8 kWReference
LS MtronReference
turbocharged dieselReference
3-cylinderReference
liquid-cooled inlineReference
Displacement1.9 LReference
Bore/Stroke88 x 103 mmReference
Power29.8 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed mechanical shuttleReference
hydrostaticReference
Typemechanical shuttleReference
Gears12 forward and reverseReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
PTO & Hydraulics
Rear TypeIReference
Rear lift (at ends)937 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Workmaster 40C Serial Numbers
Location:Serial number decal on the left side of the tractor frame, above the front axle.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
