Tractor · 2015Unverified
New Holland Workmaster 70
New Holland Workmaster 70 — Workmaster Series · 61 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
61 hp
Weight
4442 to 5059 pounds
Hover a source tag to verify
Overview
ManufacturerNew Holland (a part of CNH)Reference
Utility tractorReference
Original price was $27,216 in 2017Reference
Two- or four-wheel driveReference
Final drivesinboard planetaryReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS.Reference
Engine
FPT 2.2L 3-cyl dieselReference
Fuel tank52.2 LReference
Engine52.2 kWReference
FPT R753Reference
turbocharged dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.2 LReference
Bore/Stroke94 x 107 mmReference
EmissionsTier IVReference
Emission controlexhaust gas recirculation with particulate catalystReference
Power52.2 kWReference
Fuel systemelectronic high-pressure common rail direct injectionReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
8-speed synchronized shuttleReference
Typesynchronized shuttleReference
Gears8 forward and reverseReference
PTO & Hydraulics
PTO (claimed)45.5 kWReference
Typeopen centerReference
Valves1 or 2Reference
Pump flow45.4 lpmReference
Total flow66.2 lpmReference
Steering flow20.8 lpmReference
Rear TypeII/IReference
Controlposition and draft controlReference
Rear lift (at ends)1500 kgReference
Rear lift (at 24"/610mm)1225 kgReference
Rear Armstelescoping draft linksReference
Rear PTOindependentReference
ClutchmechanicalReference
Rear PTO Type540Reference
Rear PTO Type540/540EReference
Dimensions
2WD Wheelbase244 cmReference
4WD Wheelbase247 cmReference
Weight4442 to 5059 poundsReference
Front tire7.5x16Reference
2WD Rear tire14.9x28Reference
Weight387 kgReference
2WD Standard tires (ag)Front: 7.5x16. Rear: 14.9x28Reference
4WD Standard tires (ag)Front: 9.5x24. Rear: 14.9x28Reference
Industrial front12.5x18Reference
Industrial rear18.4x24Reference
2WD Length328 cmReference
4WD Length340 cmReference
Width196 cmReference
Height (ROPS)247 cmReference
2WD Weight2014 kgReference
4WD Weight2294 kgReference
Flange rear axleReference
New Holland Workmaster 70 attachments
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps75Reference
Battery volts12Reference
Attachment overview
New Holland 611TL loaderReference
New Holland 616TL loaderReference
New Holland 621TL loaderReference
New Holland 626TL loaderReference
BackhoeReference
New Holland 935GHB Backhoe
Backhoe typeNew Holland 935GHB BackhoeReference
Transport height223 cmReference
Digging depth254 cmReference
Reach from pivot330 cmReference
Loading height193 cmReference
Bucket Rotation180°Reference
Swing Arc175°Reference
Bucket force2032 kgReference
Dipperstick force1148 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
