Tractor · 2019Unverified
New Holland Workmaster 95
New Holland Workmaster 95 — Workmaster Series · 97 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
97 hp
Weight
7738 to 8637 pounds
Hover a source tag to verify
Overview
ManufacturerNew HollandReference
Utility tractorReference
Original price$67,370 (2022 ROPS )Reference
Original price$83,837 (2022 Cab )Reference
Four-wheel driveReference
Final drivesinboard planetaryReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS. Cab optional with air-conditioning.Reference
Engine
FPT 3.4L 4-cyl dieselReference
ROPS Fuel tank90.8 LReference
Cab Fuel tank109.8 LReference
Exhaust fluid (DEF)11.0 LReference
Engine (gross)72.3 kWReference
FPT F5Reference
turbocharged aftercooled dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.4 LReference
Bore/Stroke99 x 110 mmReference
EmissionsTier 4Reference
Power (gross)72.3 kWReference
Rated RPM2300Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed power shuttleReference
Typepower shuttleReference
Gears12 forward and reverseReference
Four synchronized gears in three ranges with power shuttle.Reference
PTO & Hydraulics
PTO (claimed)58.2 kWReference
Typeopen centerReference
Rear valves2 or 3Reference
Pump flow64.0 lpmReference
Pump flow81.8 lpmReference
Steering flow36.7 lpmReference
Rear TypeII/IReference
Rear lift (at 24"/610mm)1451 kgReference
Rear lift (at 24"/610mm)2812 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulic wet discReference
Rear PTO Type540Reference
Rear PTO Type540/540E l 540/1000 ) ((Optional)Reference
Dimensions
ROPS Wheelbase212 cmReference
Cab Wheelbase225 cmReference
Weight7738 to 8637 poundsReference
Front tire12.4-24Reference
Rear tire18.4-30Reference
Standard tires (ag)Front: 12.4-24. Rear: 18.4-30Reference
Optional tires (ag)Front: 13.6-24. Rear: 16.9-34Reference
Length409 cmReference
Height (ROPS)261 cmReference
Height (cab)267 cmReference
ROPS Weight3509 kgReference
Cab Weight3917 kgReference
Flange rear axleReference
New Holland Workmaster 95 attachments
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps120Reference
Battery volts12Reference
Attachment overview
New Holland 632TL loaderReference
New Holland 637TL loaderReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
