Tractor · 1964Unverified
Nuffield 10/60
Nuffield 10/60 — Utility tractor · 55 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
55 hp
Max power
34.3 kW
Weight
2660 kg
Hover a source tag to verify
Overview
ManufacturerNuffieldReference
Utility tractorReference
Two-wheel driveReference
Differential lockmechanicalReference
SteeringmanualReference
Steeringpower assist optionalReference
Independent mechanical disc brakesReference
Open operator station.Reference
Engine
BMC 3.8L 4-cyl dieselReference
Drawbar (tested)34.3 kWReference
BMC 38TReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.8 LReference
Bore/Stroke100 x 120 mmReference
Air cleaneroil bathReference
Compression16.5:1Reference
Rated RPM2000Reference
Starter volts12Reference
Power at rated engine speed41.3 kWReference
Max power34.3 kWReference
Transmission
10-speedReference
Gears10 forward and 2 reverseReference
Clutchdry discReference
PTO & Hydraulics
PTO (claimed)41.0 kWReference
PTO (tested)41.3 kWReference
Pressure137.9 barReference
Total flow22.7 lpmReference
Rear TypeII/IReference
Rear lift (at ends)1283 kgReference
Rear PTOindependentReference
Rear PTO Type540Reference
Power at rated PTO speed32.2 kWReference
Dimensions
Weight2660 kgReference
Front tire7.50-16Reference
Rear tire16.9-30Reference
Ag front7.50-16Reference
Ag rear16.9-30Reference
Operating weight2660 kgReference
Ballasted weight4615 kgReference
Test results
Diesel 10-speed 2WDAugust 6 - 12, 1965Link: Nebraska Tractor Test 907 fileReference
PTO performanceReference
Fuel use14.8 l/hourReference
Fuel use11.0 l/hourReference
Drawbar performanceReference
Fuel use14.4 l/hourReference
Gear 3L used for power test.Reference
Max pull3477 kgReference
Gear 2L used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
