Lawn Tractor · 1972Unverified
Oliver 125
Oliver 125 — Garden tractor · 12 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
12 hp
Weight
750 to 770 pounds
Hover a source tag to verify
Overview
DistributorOliverReference
ManufacturerJacobsenReference
Garden tractorReference
Original price$1285 (1972 gear)Reference
Original price$1480 (1972 hydro)Reference
Two-wheel driveReference
Manual steeringReference
Mechanical band brakesReference
Open operator station.Reference
Variants
125Ggear driveReference
125HhydrostaticReference
GT-12similar Jacobsen modelReference
Engine
12HP Kohler 476cc 1-cyl gasolineReference
Fuel tank7.6 LReference
Kohler K301ASReference
gasolineReference
1-cylinderReference
air-cooled horizontal-shaftReference
Displacement29.07 ciReference
Bore/Stroke86 x 83 mmReference
Power (gross)8.9 kWReference
Air cleanerdryReference
Rated RPM3600Reference
Starter volts12Reference
Oil capacity2.0 LReference
Transmission
4-speed gearReference
Gear Weight340 kgReference
Typebelt-driven gearReference
Gears4 forward and 1 reverseReference
Clutchidler pulleyReference
Transmissionshaft-driven hydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
Typesleeve hitchReference
Front PTOindependentReference
ClutchelectricReference
Front PTO TypepulleyReference
Dimensions
Wheelbase121 cmReference
Weight750 to 770 poundsReference
Front tire16x6.50-8Reference
Rear tire23x8.50-12Reference
Lawn/turf front16x6.50-8Reference
Lawn/turf rear23x8.50-12Reference
Length182 cmReference
Width96 cmReference
Height (steering wheel)105 cmReference
Height (hood)92 cmReference
Hydro Weight349 kgReference
Clearance (front axle)23 cmReference
Clearance (rear axle)20 cmReference
Oliver 125 attachments
42" mid-mount mower deckReference
50" mid-mount mower deckReference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
42" mid-mount mower deckReference
50" mid-mount mower deckReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
