Tractor · 1974Unverified
Oliver 1270
Oliver 1270 — Fiat built · 41 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
41 hp
Weight
1728 kg
Hover a source tag to verify
Overview
DistributorOliverReference
ManufacturerFiatReference
Two- or four-wheel driveReference
Open operator station.Reference
Engine
Fiat 2.6L 3-cyl dieselReference
FiatReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.6 LReference
Bore/Stroke100 x 110 mmReference
Pre-heatingthermostartReference
Compression17:1Reference
Rated RPM2400Reference
Starter volts12Reference
Oil capacity7.6 LReference
Coolant capacity12.8 LReference
Transmission
9-speedReference
Gears9 forward and 2 reverseReference
PTO & Hydraulics
PTO (claimed)30.6 kWReference
Dimensions
Weight1728 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
