Backhoe Loader · 1964Unverified

Oliver 1650

Name: Oliver 1650
Brand: Oliver

Oliver 1650 — Backhoe loader tractor · 78 hp. Reference specifications; pending source verification.

The Oliver 1650 is a backhoe loader with a rated output of 78 hp — putting it around the middle of its class for power. This model was produced from 1964 to 1969. Under the hood is a 6-cylinder diesel liquid-cooled engine, driving through four-wheel drive with a powershift transmission. Listed weight is 12780 to 12880 pounds, and it is aimed at jobs of around up to 200 ac. Full UK and US specifications are listed below, each with its source.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

78 hp

Weight

12780 to 12880 pounds

Catalogue coverage

Variants represented

Richest spec table

51 rows

Recorded power

78 hp

Recorded weight

5797 kg

Transmissions

6-speed power shift

Production years

1964-1969

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerOliver (a part of White)Reference

Backhoe loader tractorReference

Four-wheel driveReference

Open operator station.Reference

Engine

Waukesha-Oliver 4.6L 6-cyl dieselReference

Waukesha-Oliver 4.3L 6-cyl gasolineReference

Engine (net)58.2 kWReference

Waukesha-OliverReference

dieselReference

6-cylinderReference

liquid-cooledReference

Displacement4.6 LReference

Bore/Stroke98 x 102 mmReference

Power (net)58.2 kWReference

Air cleanerdryReference

Compression16:1Reference

Rated RPM2200Reference

Starter typeelectricReference

gasolineReference

Displacement4.3 LReference

Bore/Stroke95 x 102 mmReference

Compression8.5:1Reference

Transmission

6-speed power shiftReference

6-speed gearReference

Typepower shiftReference

Gears6 forward and reverseReference

TypegearReference

Gears6 forward and 2 reverseReference

PTO & Hydraulics

Typeopen centerReference

Pump flow102.2 lpmReference

Dimensions

Weight12780 to 12880 poundsReference

Front tire8.25x20Reference

Rear tire16.9x28Reference

Industrial front8.25x20Reference

Industrial rear16.9x28Reference

Length739 cmReference

Height (backhoe)320 cmReference

Gas Shipping weight5797 kgReference

Diesel Shipping weight5842 kgReference

Front tread165/182 cmReference

Rear tread181 cmReference

Backhoe & Loader

Dig depth457 cmReference

Dump angle114 cmReference

Attachment overview

Front-end loaderReference

BackhoeReference

Oliver Backhoe

Backhoe typeOliver BackhoeReference

Transport height320 cmReference

Digging depth457 cmReference

Reach from pivot520 cmReference

Loading height281 cmReference

Swing Arc180°Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
