Tractor · 1967Unverified

Oliver 1950-T

Oliver 1950-T — 50 Series · 105 hp. Reference specifications; pending source verification.

The Oliver 1950-T is a tractor with a rated output of 105 hp, positioned near the middle of its class in terms of power. Manufactured from 1967 to 1969, it features a 6-cylinder turbocharged diesel liquid-cooled engine, which powers a four-wheel drive system via a powershift transmission. The tractor's listed weight ranges from 10460 to 11490 pounds. It is designed to manage land areas of approximately 200 to 800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power
105 hp
Max power
52.3 kW
Weight
10460 to 11490 pounds

Catalogue coverage

Variants represented
2
Richest spec table
82 rows
Recorded power
105 hp
Transmissions
6-speed gear
Production years
1967-1969
Verified variants
0

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerOliverReference
Row-Crop tractorReference
Two- or four-wheel driveReference
Steeringhydraulic powerReference
Differential disc brakesReference
Open operator station. Optional cab.Reference

Engine

Waukesha-Oliver 5.1L 6-cyl dieselReference
Fuel tank104.1 LReference
Fuel tank295.2 LReference
Drawbar (tested)66.4 kWReference
Waukesha-OliverReference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement5.1 LReference
Bore/Stroke98 x 111 mmReference
Air cleanerdual dry pre-cleanersReference
Compression16:1Reference
Rated RPM2400Reference
Starter volts12Reference
Oil capacity10.9 LReference
Coolant capacity18.9 LReference
Power at rated engine speed78.5 kWReference
Max power52.3 kWReference
Power at rated engine speed78.4 kWReference
Max power66.4 kWReference

Transmission

6-speed gearReference
12-speed two-speed power shiftReference
18-speed partial power shiftReference
TypegearReference
Gears6 forward and 2 reverseReference
Clutch330mm cera-metallic discReference
TransmissionHydra-PowerReference
Typetwo-speed power shiftReference
Gears12 forward and 6 reverseReference
TransmissionHydraul-ShiftReference
Typepartial power shiftReference
Gears18 forward and 6 reverseReference
The Hydraul-Shift provides an on-the-move power shift to a higher or lower range for each of the six forward, and two reverse, gears.Reference

PTO & Hydraulics

PTO (claimed)78.3 kWReference
PTO (tested)78.5 kWReference
Typeopen centerReference
Pressure141.3 barReference
Pump flow63.2 lpmReference
Rear TypeIIReference
Rear TypeIIIReference
Controlposition and lower-link draft controlReference
Rear lift (at ends)2721 kgReference
Rear PTO Type540Reference
Rear PTO Type540/1000Reference

Dimensions

Wheelbase277 cmReference
Weight10460 to 11490 poundsReference
Length405 cmReference
Height (steering wheel)201 cmReference
Ground clearance64 cmReference
Front tread171 to 232 cmReference
Rear tread170 to 276 cmReference
Operating4744 kgReference
Operating5211 kgReference
Ballasted9171 kgReference

Oliver 1950-T attachments

front-end loaderReference

1950-T Serial Number Location

Serial number plate below the tractor's instrument panel.Reference

1950-T Serial Numbers

1967188974Reference
1968201931Reference
1969213376Reference
Final218449Reference
FAQ: How to read a serial number table.Reference

Test results

NTTL 969: diesel Hydaul-Shift 2WDReference
NTTL 972: diesel Hydraul-Shift 4WDReference
Diesel Hydaul-Shift 2WDNovember 13 - 18, 1967Link: Nebraska Tractor Test 969 fileReference
PTO performanceReference
Fuel use24.6 l/hourReference
Drawbar performanceReference
Fuel use18.5 l/hourReference
Gear 4-Under used for power test.Reference
Max pull5844 kgReference
Gear 1-Over used for pull test.Reference
Diesel Hydraul-Shift 4WDApril 29 - May 7, 1968Link: Nebraska Tractor Test 972 fileReference
Fuel use25.0 l/hourReference
Gear 3-Direct used for power test.Reference
Max pull8025 kgReference
Gear 1-Direct used for pull test.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
