Tractor · 1942Unverified
Oliver 60 Standard
Oliver 60 Standard — Standard-tread tractor · 18 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
18 hp
Hover a source tag to verify
Overview
ManufacturerOliverReference
Standard-tread tractorReference
Built in Charles City, Iowa, USAReference
Two-wheel driveReference
Manual steeringReference
Differential contracting band brakesReference
Open operator station.Reference
Variants
60 Row-Croptricycle frontReference
60 Standardfixed front treadReference
60 Industrialindustrial tractorReference
Engine
Oliver 2.0L 4-cyl gasolineReference
Plows1-2Reference
OliverReference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement2.0 LReference
Bore/Stroke84 x 89 mmReference
Fuel systemSchebler carburetorReference
Air cleaneroil bathReference
Rated RPM1500Reference
Transmission
4-speed gearReference
6-speedReference
TypegearReference
Gears4 forward and 1 reverseReference
Clutchdry discReference
Gears6 forward and 2 reverseReference
PTO & Hydraulics
PTO (claimed)13.4 kWReference
60 Standard Serial Numbers
1942410001 (standard)Reference
1943410501 (standard)Reference
1944410511 (standard)Reference
1945410617 (standard)Reference
1946410911 (standard)Reference
1947411311 (standard)Reference
1948411961 (standard)Reference
1946460001 (industrial)Reference
1947460301 (industrial)Reference
1948460501 (industrial)Reference
FAQ: How to read a serial number table.Reference
Capacities
Diameter25 cmReference
Width13 cmReference
RPM1143Reference
Speed914.40 meters/minReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
