Tractor · 1962Unverified
Oliver 600
Oliver 600 — Utility tractor · 48 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
48 hp
Weight
1955 kg
Hover a source tag to verify
Overview
DistributorOliverReference
ManufacturerDavid BrownReference
Utility tractorReference
Built in Meltham Mills, Huddersfield, EnglandReference
Two-wheel driveReference
Differential lockmechanical rearReference
Open operator station.Reference
Variants
990similar David Brown modelReference
Engine
David Brown 3.0L 4-cyl dieselReference
Fuel tank43.5 LReference
Drawbar (claimed)32.1 kWReference
David BrownReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.0 LReference
Bore/Stroke92 x 114 mmReference
Air cleaneroil bathReference
Compression17:1Reference
Rated RPM2200Reference
Idle RPM700-2200Reference
Starter volts12Reference
Oil capacity3.1 LReference
Coolant capacity11.4 LReference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 2 reverseReference
PTO & Hydraulics
PTO (claimed)35.8 kWReference
Rear TypeII/IReference
Rear PTOliveReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase194 cmReference
Weight1955 kgReference
Front tire6.00-16Reference
Rear tire14.9/13-28Reference
Ag front6.00-16Reference
Ag rear14.9/13-28Reference
Ag front7.50-16Reference
Ag rear11-32Reference
Ag rear14-30Reference
Length299 cmReference
Width162 cmReference
Height (hood)142 cmReference
Clearance (front axle)50 cmReference
Front tread132 to 193 cmReference
Rear tread132 to 193 cmReference
Speeds
With 13-28 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
