Tractor · 1962Unverified

Oliver 600

Name: Oliver 600
Brand: Oliver

Oliver 600 — Utility tractor · 48 hp. Reference specifications; pending source verification.

The Oliver 600 is a tractor model with a rated power of 48 hp, which positions it at the lower end of its power class. It was manufactured between 1962 and 1964. Power is provided by a 4-cylinder diesel liquid-cooled engine, coupled with a two-wheel drive system and a 6-speed gearbox. Its operational weight is listed as 1955 kg, and it is suitable for managing areas up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

48 hp

Weight

1955 kg

Catalogue coverage

Variants represented

Richest spec table

47 rows

Recorded power

48 hp

Recorded weight

1955 kg

Transmissions

6-speed gear

Production years

1962-1964

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

DistributorOliverReference

ManufacturerDavid BrownReference

Utility tractorReference

Built in Meltham Mills, Huddersfield, EnglandReference

Two-wheel driveReference

Differential lockmechanical rearReference

Open operator station.Reference

Variants

990similar David Brown modelReference

Engine

David Brown 3.0L 4-cyl dieselReference

Fuel tank43.5 LReference

Drawbar (claimed)32.1 kWReference

David BrownReference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement3.0 LReference

Bore/Stroke92 x 114 mmReference

Air cleaneroil bathReference

Compression17:1Reference

Rated RPM2200Reference

Idle RPM700-2200Reference

Starter volts12Reference

Oil capacity3.1 LReference

Coolant capacity11.4 LReference

Transmission

6-speed gearReference

TypegearReference

Gears6 forward and 2 reverseReference

PTO & Hydraulics

PTO (claimed)35.8 kWReference

Rear TypeII/IReference

Rear PTOliveReference

Rear PTO Type540/1000Reference

Dimensions

Wheelbase194 cmReference

Weight1955 kgReference

Front tire6.00-16Reference

Rear tire14.9/13-28Reference

Ag front6.00-16Reference

Ag rear14.9/13-28Reference

Ag front7.50-16Reference

Ag rear11-32Reference

Ag rear14-30Reference

Length299 cmReference

Width162 cmReference

Height (hood)142 cmReference

Clearance (front axle)50 cmReference

Front tread132 to 193 cmReference

Rear tread132 to 193 cmReference

Speeds

With 13-28 rear tires.Reference
