Tractor · 1937Unverified
Oliver 80 Standard
Oliver 80 Standard — Standard-tread tractor · 36 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
36 hp
Max power
21.3 kW
Weight
2177 kg
Hover a source tag to verify
Overview
ManufacturerOliverReference
Standard-tread tractorReference
Built in Charles City, Iowa, USAReference
Two-wheel driveReference
SteeringmanualReference
Open operator station.Reference
Variants
Row-crop 80tricycle-frontReference
Standard 80fixed-treadReference
35industrial tractorReference
Engine
Waukesha-Oliver 5.5L 4-cyl keroseneReference
Waukesha-Oliver 4.9L 4-cyl gasolineReference
Fuel tank49.2 LReference
Fuel tank64.3 LReference
Plows3Reference
Drawbar (tested)26.8 kWReference
Belt (tested)30.8 kWReference
Waukesha-OliverReference
keroseneReference
4-cylinderReference
liquid-cooledReference
Displacement5.5 LReference
Bore/Stroke114 x 133 mmReference
Air cleaneroil bathReference
Rated RPM1200Reference
Starter typehand-crankReference
Starter typeelectric (optional)Reference
gasolineReference
Displacement4.9 LReference
Bore/Stroke108 x 133 mmReference
Starter typeelectricReference
Belt power (max)29.3 kWReference
Max power21.3 kWReference
Belt power (max)30.8 kWReference
Max power26.8 kWReference
Transmission
3-speed gearReference
4-speed gearReference
TypegearReference
Gears3 forward and 1 reverseReference
Clutchdry discReference
Gears4 forward and 1 reverseReference
The four-speed transmission was added to the Standard 80 in 1938.Reference
Dimensions
Weight2177 kgReference
Front tire7.50-18Reference
Rear tire11.25-24Reference
Ag front7.50-18Reference
Ag rear11.25-24Reference
Ag rear12.75-24Reference
Ballasted weight3628 kgReference
Front tread120 cmReference
Rear tread137 cmReference
80 Standard Serial Numbers
1937803929Reference
1938803991 (3-speed)Reference
1938805320 (4-speed)Reference
1939805337Reference
1940806880Reference
1941808125Reference
1942809051Reference
1943809991Reference
1944810470Reference
1945811911Reference
1946813067Reference
1947814564Reference
1948815216Reference
Final816241Reference
FAQ: How to read a serial number table.Reference
Test results
NTTL 301: kerosene 3-speed 2WDReference
NTTL 301: gasoline 3-speed 2WDReference
Kerosene 3-speed 2WDMay 16, 1938 - May 28, 1936Link: Nebraska Tractor Test 301 fileReference
Belt fuel use (max)18.2 l/hourReference
Drawbar performanceReference
Gear 2 used for power test.Reference
Max pull1631 kgReference
Gear 1 used for pull test.Reference
Gasoline 3-speed 2WDNovember 4 - 8, 1940Link: Nebraska Tractor Test 301 fileReference
Belt fuel use (max)14.4 l/hourReference
Max pull2303 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
