Tractor · 1973Unverified
Oliver G1355
Oliver G1355 — 55 Series · 143 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
143 hp
Max power
93.7 kW
Weight
7756 kg
Hover a source tag to verify
Overview
ManufacturerOliverReference
Row-Crop tractorReference
Built in Charles City, Iowa, USAReference
Original price was $11,600 in 1972Reference
Two-wheel driveReference
Final drivesplanetaryReference
Power steeringReference
Dry disc brakesReference
Open operator station. Cab optional with available air-conditioning.Reference
Engine
Minneapolis-Moline 9.6L 6-cyl dieselReference
Minneapolis-Moline 8.3L 6-cyl LP-gasReference
Fuel tank151.4 LReference
Fuel tank147.6 LReference
Drawbar (tested)93.7 kWReference
Minneapolis-MolineReference
dieselReference
6-cylinderReference
liquid-cooledReference
Displacement9.6 LReference
Bore/Stroke121 x 140 mmReference
Air cleanerdryReference
Compression15.3:1Reference
Rated RPM2200Reference
Starter volts12Reference
Oil capacity13.2 LReference
Coolant capacity31.2 LReference
LP-gasReference
Displacement8.3 LReference
Bore/Stroke117 x 127 mmReference
Compression8.8:1Reference
Oil capacity11.4 LReference
Coolant capacity28.4 LReference
Power at rated engine speed106.4 kWReference
Max power93.7 kWReference
Transmission
6-speed gearReference
18-speed three-range power shiftReference
TypegearReference
Gears6 forward and 2 reverseReference
Clutch355.6mm dry discReference
Oil capacity40.7 LReference
TransmissionHydraul-ShiftReference
Typethree-range power shiftReference
Gears18 forward and 6 reverseReference
PTO & Hydraulics
PTO (claimed)109.6 kWReference
PTO (claimed)100.7 kWReference
PTO (tested)106.4 kWReference
Typeclosed centerReference
Pressure151.7 barReference
Pump flow75.7 lpmReference
Rear TypeIII/IIReference
Rear lift2721 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase281 cmReference
Weight7756 kgReference
Front tire11.00-16Reference
Rear tire18.4-38Reference
Ag front11.00-16Reference
Ag rear18.4-38Reference
Ag front14.00L-16.1Reference
Ag rear23.1-34Reference
Ag rear20.8-38Reference
Length464 cmReference
Width207 cmReference
Height (steering wheel)217 cmReference
Height (exhaust)251 cmReference
Operating weight7756 kgReference
Ballasted weight8196 kgReference
Clearance (front axle)52 cmReference
Front tread154 to 215 cmReference
Rear tread154 to 231 cmReference
G1355 Serial Numbers
1972236442Reference
1973237875Reference
1974245258Reference
FAQ: How to read a serial number table.Reference
Test results
Diesel 18-speed 2WDSeptember 4 - 17, 1973Link: Nebraska Tractor Test 1141 fileReference
PTO performanceReference
Fuel use35.6 l/hourReference
Drawbar performanceReference
Fuel use34.8 l/hourReference
Gear 4-Direct used for power test.Reference
Max pull6431 kgReference
Gear 2-Direct used for pull test.Reference
Speeds
With 18.4-38 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
