The Pasquali 493 is a tractor rated at 42 hp — making it one of the more compact options in its class. Power comes from a 3-cylinder diesel air-cooled engine, driving through four-wheel drive with a 9-speed gearbox. Listed weight is 1195 kg, and it is aimed at jobs of around up to 200 ac. Available dimensions and performance figures follow in both unit systems.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
42 hp
Weight
1195 kg
Catalogue coverage
Variants represented
2
Richest spec table
35 rows
Recorded power
42 hp
Recorded weight
1195 kg
Transmissions
9-speed gear
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerPasqualiReference
Built in ItalyReference
Four-wheel driveReference
Differential lockmechanical front and rearReference
Articulated power steeringReference
Hydraulic disc brakesReference
Open operator station.Reference
Engine
VM 1.8L 3-cyl dieselReference
Engine31.0 kWReference
VMReference
dieselReference
3-cylinderReference
air-cooledReference
Displacement1.8 LReference
Power31.0 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
9-speed gearReference
TypegearReference
Gears9 forward and 3 reverseReference
Clutchdry discReference
PTO & Hydraulics
Rear TypeIReference
Rear PTOindependentReference
Rear PTO Type580/740Reference
Dimensions
Wheelbase131 cmReference
Weight1195 kgReference
Front tire7.50-16Reference
Rear tire9.50-20Reference
Standard tires (ag)Front: 7.50-16. Rear: 9.50-20Reference
Length276 cmReference
Width123 cmReference
Height (steering wheel)125 cmReference
Ground clearance32 cmReference
Front tread99 to 115 cmReference
Rear tread99 to 115 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
