Tractor · 2008Unverified

Pasquali ERA 9.40

Name: Pasquali ERA 9.40
Brand: Pasquali

Pasquali ERA 9.40 — Farm/Agricultural tractor · 35 hp. Reference specifications; pending source verification.

The Pasquali ERA 9.40 is a tractor with a rated output of 35 hp, making it a compact option in its class. It features a 4-cylinder diesel liquid-cooled engine, which powers the four-wheel drive through a hydrostatic transmission. The ERA 9.40 has a listed weight of 909 kg and is suitable for tasks covering areas of up to 200 acres. It was manufactured in 2008.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

35 hp

Weight

909 kg

Catalogue coverage

Variants represented

Richest spec table

34 rows

Recorded power

35 hp

Recorded weight

909 kg

Transmissions

12-speed

Production years

2008-2008

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerPasqualiReference

Farm/Agricultural tractorReference

Built in ItalyReference

Four-wheel driveReference

Steeringhydrostatic powerReference

Wet disc brakesReference

Engine

Lombardini 1.4L 4-cyl dieselReference

Engine26.1 kWReference

Lombardini LDW 1404 FOCSReference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement1.4 LReference

Power26.1 kWReference

Rated RPM3400Reference

Torque82.6 NmReference

Torque RPM2200Reference

Starter volts12Reference

Transmission

12-speedReference

Gears12 forward and reverseReference

PTO & Hydraulics

Rear TypeIReference

Rear lift (at ends)699 kgReference

Rear PTO Type540/groundReference

Mid PTOoptionalReference

Mid PTO Type2000Reference

Dimensions

Weight909 kgReference

Front tire6.5/80-12Reference

Rear tire250/70-18Reference

Ag front6.5/80-12Reference

Ag rear250/70-18Reference

Ag front25x8.50-14Reference

Ag rear280/70-18Reference

Ag rear11.5/80-15.3Reference

Ag rear320/65-18Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
