The Pasquali ORION 7.75 is a compact tractor model rated at 63 hp, manufactured in 2008. It features a 4-cylinder diesel liquid-cooled engine, coupled with a 16-speed gearbox and four-wheel drive. This configuration is suitable for tasks on areas up to 200 acres. Detailed specifications for the Pasquali ORION 7.75 are provided in both metric and imperial units.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
63 hp
Catalogue coverage
Variants represented
2
Richest spec table
36 rows
Recorded power
63 hp
Transmissions
16-speed
Production years
2008-2008
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerPasqualiReference
Farm/Agricultural tractorReference
Built in ItalyReference
Four-wheel driveReference
Wet disc brakesReference
Engine
VM Daimler-Benz 3.0L 4-cyl dieselReference
Fuel tank54.9 LReference
Engine47.0 kWReference
VM Daimler-Benz D754 E2Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.0 LReference
Power47.0 kWReference
Rated RPM2300Reference
Torque214.0 NmReference
Torque RPM1400Reference
Transmission
16-speedReference
Gears16 forward and reverseReference
PTO & Hydraulics
Rear TypeII/IReference
Rear lift (at ends)2300 kgReference
Front HitchIReference
Front lift800 kgReference
Rear PTOindependentReference
Rear PTO Type540/750Reference
Dimensions
Wheelbase149 cmReference
Front tire250/80-18Reference
Rear tire250/80-18Reference
Ag front250/80-18Reference
Ag rear250/80-18Reference
Length320 cmReference
Height (steering wheel)112 cmReference
Ground clearance23 cmReference
Electrical
Charging systemalternatorReference
Charging amps55Reference
Battery AH100Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
