The Pasquali VANTH 5.30 is a tractor model rated at 26 hp, classified as one of the more compact options in its class. The VANTH 5.30 was manufactured in 2008. It features a 3-cylinder diesel liquid-cooled engine driving through a hydrostatic transmission with four-wheel drive. The listed weight of the VANTH 5.30 is 850 kg, with a capacity for jobs of approximately 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
26 hp
Weight
850 kg
Catalogue coverage
Variants represented
2
Richest spec table
32 rows
Recorded power
26 hp
Recorded weight
850 kg
Transmissions
8-speed
Production years
2008-2008
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerPasqualiReference
Farm/Agricultural tractorReference
Built in ItalyReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Mechanical drum brakesReference
Engine
Lombardini 1.0L 3-cyl dieselReference
Engine19.4 kWReference
Lombardini LDW 1003 FOCSReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.0 LReference
Power19.4 kWReference
Rated RPM3400Reference
Torque59.0 NmReference
Torque RPM2200Reference
Starter volts12Reference
Transmission
8-speedReference
Gears8 forward and 4 reverseReference
PTO & Hydraulics
Rear TypeIReference
Rear lift (at ends)699 kgReference
Rear PTO Type540/groundReference
Dimensions
Weight850 kgReference
Front tire6.50-16Reference
Rear tire6.50-16Reference
Ag front6.50-16Reference
Ag rear6.50-16Reference
Ag front7.5L-15Reference
Ag front7.50-16Reference
Ag rear7.5L-15Reference
Ag rear7.50-16Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
