The Pasquali VANTH 6.30 is a compact tractor model with a rated output of 26 hp, one of the smaller options in its class. It was produced in 2008. The VANTH 6.30 is powered by a 3-cylinder diesel liquid-cooled engine, transmitting power to all four wheels via a hydrostatic transmission. Its listed weight is 860 kg, making it suitable for tasks covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
26 hp
Weight
860 kg
Catalogue coverage
Variants represented
2
Richest spec table
36 rows
Recorded power
26 hp
Recorded weight
860 kg
Transmissions
8-speed
Production years
2008-2008
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerPasqualiReference
Farm/Agricultural tractorReference
Built in ItalyReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Mechanical drum brakesReference
Engine
Lombardini 1.0L 3-cyl dieselReference
Engine19.4 kWReference
Lombardini LDW 1003 FOCSReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.0 LReference
Power19.4 kWReference
Rated RPM3400Reference
Torque59.0 NmReference
Torque RPM2200Reference
Starter volts12Reference
Transmission
8-speedReference
Gears8 forward and 4 reverseReference
PTO & Hydraulics
Rear TypeIReference
Rear lift (at ends)699 kgReference
Rear PTO Type540/groundReference
Dimensions
Weight860 kgReference
Front tire6.50-16Reference
Rear tire6.50-16Reference
Ag front6.50-16Reference
Ag rear6.50-16Reference
Ag front7.5L-15Reference
Ag front7.50-16Reference
Ag front260/70-16Reference
Ag rear7.5L-15Reference
Ag rear7.50-16Reference
Ag rear260/70-16Reference
Lawn/turf front28x9.00-15Reference
Lawn/turf rear28x9.00-15Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
