Tractor · 1918Unverified
Pioneer Tractor Special
Pioneer Tractor Special — Standard-tread tractor · 15 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
15 hp
Weight
2857 kg
Hover a source tag to verify
Overview
ManufacturerPioneer TractorReference
Standard-tread tractorReference
Built in Winona, Minnesota, USAReference
Two-wheel driveReference
SteeringmanualReference
Open operator station.Reference
Engine
Pioneer Tractor 9.3L 4-cyl gasolineReference
Drawbar (claimed)11.2 kWReference
Belt (claimed)22.4 kWReference
Plows4 (14-inch)Reference
Pioneer TractorReference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement9.3 LReference
Bore/Stroke140 x 152 mmReference
Rated RPM700Reference
Transmission
3-speed gearReference
TypegearReference
Gears3 forward and 1 reverseReference
Dimensions
Wheelbase294 cmReference
Weight2857 kgReference
Front tire36x6Reference
Rear tire60x18Reference
Ag front36x6 (steel)Reference
Ag rear60x18 (steel)Reference
Length426 cmReference
Width193 cmReference
Height167 cmReference
Rear axle104 mmReference
Capacities
Diameter35 cmReference
Width17 cmReference
RPM510Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
