Tractor · 1957Unverified
Porsche Super
Porsche Super — Utility tractor · 37 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
37 hp
Max power
24.1 kW
Weight
2194 kg
Hover a source tag to verify
Overview
ManufacturerPorscheReference
Utility tractorReference
Built in GermanyReference
Two-wheel driveReference
Manual steeringReference
Drum brakesReference
Open operator station.Reference
Engine
Porsche 2.5L 3-cyl dieselReference
Porsche 2.6L 3-cyl dieselReference
Engine28.3 kWReference
Drawbar (tested)24.1 kWReference
Porsche 308Reference
dieselReference
3-cylinderReference
air-cooledReference
Displacement2.5 LReference
Bore/Stroke95 x 116 mmReference
Power28.3 kWReference
Air cleaneroil bathReference
Compression19:1Reference
Rated RPM2000Reference
Starter volts12Reference
Porsche 329Reference
Displacement2.6 LReference
Bore/Stroke98 x 116 mmReference
Power26.1 kWReference
Rated RPM2300Reference
Power at rated engine speed27.7 kWReference
Max power24.1 kWReference
Transmission
5-speed gearReference
8-speed gearReference
TypegearReference
Gears5 forward and 1 reverseReference
Gears8 forward and 4 reverseReference
Clutchdry discReference
PTO & Hydraulics
PTO (tested)27.7 kWReference
Rear PTO Type1000Reference
Power at rated PTO speed25.3 kWReference
Dimensions
Wheelbase199 cmReference
Weight2194 kgReference
Front tire6.00-19Reference
Rear tire11-36Reference
Ag front6.00-19Reference
Ag rear11-36Reference
Ag front6.50-20Reference
Ag rear14-28Reference
Length323 cmReference
Width182 cmReference
Height (steering wheel)166 cmReference
Operating weight2194 kgReference
Ballasted weight3730 kgReference
Ground clearance40 cmReference
Capacities
Diameter21 cmReference
Width14 cmReference
RPM1460Reference
Speed1007.97 meters/minReference
Test results
Diesel 8-speed 2WDNovember 14 - 21, 1959Link: Nebraska Tractor Test 728 fileReference
PTO performanceReference
Fuel use11.0 l/hourReference
Fuel use9.1 l/hourReference
Drawbar performanceReference
Gear 6 used for power test.Reference
Max pull2908 kgReference
Gear 3 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
