Tractor · 2005Unverified
Ranch Hand 4452
Ranch Hand 4452 — Compact Utility tractor · 45 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
45 hp
Hover a source tag to verify
Overview
ManufacturerRanch HandReference
Compact Utility tractorReference
Four-wheel driveReference
Differential lockmechanical rearReference
Two-post folding ROPS.Reference
Variants
DXLloaderReference
4452CcabReference
Engine
Fujian 3.0L 3-cyl dieselReference
Engine33.6 kWReference
Fujian SL3105BT2Reference
dieselReference
3-cylinderReference
liquid-cooled inlineReference
Displacement3.0 LReference
Bore/Stroke105 x 110 mmReference
Power33.6 kWReference
Rated RPM2200Reference
Starter volts12Reference
Transmission
8-speed shuttleReference
TypeshuttleReference
Gears8 forward and reverseReference
PTO & Hydraulics
Rear TypeIReference
Rear PTOliveReference
Electrical
GroundnegativeReference
Batteries2Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
