Lawn Tractor · 2018Unverified

RedMax YT2142F 96043023600

Name: RedMax YT2142F 96043023600
Brand: RedMax

RedMax YT2142F 96043023600 — Lawn tractor · 22 hp. Reference specifications; pending source verification.

The RedMax YT2142F 96043023600 is a lawn tractor with a rating of 22 hp, categorising it among higher-powered machines in its class. Manufactured between 2018 and 2022, it features a 2-cylinder petrol air-cooled engine, driving through two-wheel drive with a hydrostatic transmission. The tractor is designed for use on areas of around 200 acres. Specifications for both the UK and US markets are available.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

22 hp

Catalogue coverage

Variants represented

Richest spec table

46 rows

Recorded power

22 hp

Transmissions

hydrostatic

Production years

2018-2022

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerRedMax (a part of Husqvarna)Reference

Lawn tractorReference

Original price was $3,100 in 2021Reference

Two-wheel driveReference

Differential lockrear standardReference

Manual steeringReference

Open operator station.Reference

Engine

21.5HP Kawasaki 726cc 2-cyl gasolineReference

Fuel tank15.1 LReference

Kawasaki FR651VReference

gasolineReference

2-cylinderReference

air-cooled vertical-shaft V-TwinReference

Displacement44.3 ciReference

Bore/Stroke78 x 76 mmReference

Power (gross)16.0 kWReference

StarterelectricReference

Starter volts12Reference

SparkplugNGK BPR4ESReference

Sparkplug gap0.762 mmReference

Oil capacity1.9 LReference

Oil change50 hReference

Transmission

hydrostaticReference

TransmissionTuff Torq K46CRReference

Typebelt-driven hydrostaticReference

Gearsinfinite forward and reverseReference

Oil changesealed unit, owner service is not recommendedReference

PTO & Hydraulics

Mid PTOindependentReference

ClutchelectricReference

Dimensions

Front tire15x6-6Reference

Rear tire20x10-8Reference

Lawn/turf front15x6-6Reference

Lawn/turf rear20x10-8Reference

Length175 cmReference

Height105 cmReference

Front axleCast-ironReference

RedMax YT2142F attachments

42" mid-mount mower deckReference

Electrical

GroundnegativeReference

Charging amps15Reference

Battery CCA230Reference

Battery volts12Reference

Battery AH28Reference

Battery GroupU1RReference

42" Mower deck

Typemid-mount RedMaxReference

Type2-blade with manual liftReference

Cutting width106 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
