Lawn Tractor · 2018Unverified

RedMax YT2348F

Name: RedMax YT2348F
Brand: RedMax

RedMax YT2348F — Lawn tractor · 23 hp. Reference specifications; pending source verification.

The RedMax YT2348F is a lawn tractor rated at approximately 23 hp, placing it at the more powerful end of its class. It was manufactured from 2018 to 2022. This model features a 2-cylinder petrol air-cooled engine, paired with two-wheel drive and a hydrostatic transmission. It is suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

23 hp

Catalogue coverage

Variants represented

Richest spec table

46 rows

Recorded power

23 hp

Transmissions

hydrostatic

Production years

2018-2022

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerRedMax (a part of Husqvarna)Reference

Lawn tractorReference

Original price was $3,400 in 2021Reference

Two-wheel driveReference

Differential lockrear standardReference

Manual steeringReference

Open operator station.Reference

Engine

23HP Kawasaki 726cc 2-cyl gasolineReference

Fuel tank15.1 LReference

Kawasaki FR691Reference

gasolineReference

2-cylinderReference

air-cooled vertical-shaft V-TwinReference

Displacement44.3 ciReference

Bore/Stroke78 x 76 mmReference

Power (gross)17.2 kWReference

StarterelectricReference

Starter volts12Reference

SparkplugNGK BPR4ESReference

Sparkplug gap0.762 mmReference

Oil capacity1.9 LReference

Oil change50 hReference

Transmission

hydrostaticReference

TransmissionTuff Torq K46CRReference

Typebelt-driven hydrostaticReference

Gearsinfinite forward and reverseReference

Oil changesealed unit, owner service is not recommendedReference

PTO & Hydraulics

Mid PTOindependentReference

ClutchelectricReference

Dimensions

Front tire16.5x6.5-8Reference

Rear tire22x9.5-12Reference

Lawn/turf front16.5x6.5-8Reference

Lawn/turf rear22x9.5-12Reference

Length179 cmReference

Height107 cmReference

Front axleCast-ironReference

RedMax YT2348F attachments

48" mid-mount mower deckReference

Electrical

GroundnegativeReference

Charging amps15Reference

Battery CCA230Reference

Battery volts12Reference

Battery AH28Reference

Battery GroupU1RReference

48" Mower deck

Typemid-mount RedMaxReference

Type3-blade with manual liftReference

Cutting width121 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
