Tractor · 1981Unverified
Renault 103-12 TX
Renault 103-12 TX — TX Series · 87 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
87 hp
Weight
4080 kg
Hover a source tag to verify
Overview
ManufacturerRenaultReference
Row-Crop tractorReference
Two-wheel driveReference
Power steeringReference
Hydraulic dry disc brakesReference
Cab standard with heat.Reference
Variants
103-144WDReference
Engine
MWM 4.2L 4-cyl dieselReference
Fuel tank124.9 LReference
Engine68.0 kWReference
MWM TD226-4Reference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.2 LReference
Bore/Stroke105 x 120 mmReference
Power68.0 kWReference
Air cleaneroil bathReference
Rated RPM2350Reference
Torque310.1 NmReference
Torque RPM1500Reference
Starter volts12Reference
Transmission
12-speed synchronizedReference
16-speed creeperReference
TypesynchronizedReference
Gears12 forward and reverseReference
Clutch310mm cerametallic discReference
TypecreeperReference
Gears16 forward and reverseReference
PTO & Hydraulics
PTO (claimed)65.1 kWReference
Pressure180.0 barReference
Total flow41.6 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift4100 kgReference
Rear PTOindependentReference
ClutchorganicReference
Rear PTO Type540/1000 (1.375)Reference
Dimensions
Wheelbase247 cmReference
Weight4080 kgReference
Front tire9.00-16Reference
Rear tire16.9-38Reference
Ag front9.00-16Reference
Ag rear16.9-38Reference
Length430 cmReference
Width202 cmReference
Height277 cmReference
Max weight6650 kgReference
Speeds
With 16.9-38 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
