Tractor · 1986Unverified
Renault 110-14
Renault 110-14 · 100 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
100 hp
Weight
5351 kg
Hover a source tag to verify
Overview
ManufacturerRenaultReference
Four-wheel driveReference
Power steeringReference
Dry disc brakesReference
Cab standard with available air-conditioning.Reference
Variants
TS16economyReference
TX16standardReference
Engine
MWM 6.2L 6-cyl dieselReference
Fuel tank199.8 LReference
Engine74.6 kWReference
MWM D226-6Reference
dieselReference
6-cylinderReference
liquid-cooledReference
Displacement6.2 LReference
Bore/Stroke105 x 120 mmReference
Power74.6 kWReference
Air cleanerdryReference
Rated RPM2350Reference
Torque385.1 NmReference
Torque RPM1500Reference
Transmission
16-speed mechanical shuttleReference
Typemechanical shuttleReference
Gears16 forward and reverseReference
Clutchdry discReference
PTO & Hydraulics
Pressure200.0 barReference
Total flow41.5 lpmReference
Total flow60.9 lpmReference
Rear TypeIIReference
Rear TypeIIIReference
Rear lift7121 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM644@2350Reference
Engine RPM1105@2350Reference
Front PTOindependentReference
Front PTO Type540 (1.375)Reference
Engine RPM1036@2350Reference
Dimensions
Wheelbase274 cmReference
Weight5351 kgReference
Front tire14.9-28Reference
Rear tire16.9-38Reference
Ag front14.9-28Reference
Ag rear16.9-38Reference
Length496 cmReference
Width205 cmReference
Height (cab)290 cmReference
Clearance (front axle)50 cmReference
Clearance (rear axle)54 cmReference
Front tread160 to 199 cmReference
Rear tread139 to 199 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
