Tractor · 1980Unverified
Renault 1181S
Renault 1181S · 118 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
118 hp
Weight
5391 kg
Hover a source tag to verify
Overview
ManufacturerRenaultReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Dry disc brakesReference
standardReference
Engine
MWM 6.2L 6-cyl dieselReference
Fuel tank205.1 LReference
Engine88.0 kWReference
MWM D226-6Reference
dieselReference
6-cylinderReference
Displacement6.2 LReference
Bore/Stroke105 x 120 mmReference
Power88.0 kWReference
Rated RPM2350Reference
Torque400.0 NmReference
Torque RPM1500Reference
Transmission
12-speedReference
Gears12 forward and reverseReference
PTO & Hydraulics
Total flow32.9 lpmReference
Rear lift5101 kgReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase267 cmReference
Weight5391 kgReference
Front tire14.9-28Reference
Rear tire16.9-38Reference
Ag front14.9-28Reference
Ag rear16.9-38Reference
Length448 cmReference
Height274 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
