Tractor · 1986Unverified

Renault 120-14

Name: Renault 120-14
Brand: Renault

Renault 120-14 · 110 hp. Reference specifications; pending source verification.

The Renault 120-14 is a tractor with a rated power output of 110 hp, falling within the mid-range of its class. It was manufactured from 1986 to 1989. It features a 6-cylinder diesel liquid-cooled engine, coupled with four-wheel drive and a 16-speed gearbox. The tractor's operating weight is approximately 5316 kg, suitable for operations involving 200–800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

110 hp

Weight

5316 kg

Catalogue coverage

Variants represented

Richest spec table

51 rows

Recorded power

110 hp

Recorded weight

5316 kg

Transmissions

16-speed mechanical shuttle

Production years

1986-1989

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerRenaultReference

Four-wheel driveReference

Power steeringReference

Dry disc brakesReference

Cab standard with available air-conditioning.Reference

Variants

TS16economyReference

TX16standardReference

TZ16deluxeReference

Engine

MWM 6.2L 6-cyl dieselReference

Fuel tank199.8 LReference

Engine82.0 kWReference

MWM D226-6Reference

dieselReference

6-cylinderReference

liquid-cooledReference

Displacement6.2 LReference

Bore/Stroke105 x 120 mmReference

Power82.0 kWReference

Air cleanerdryReference

Rated RPM2350Reference

Torque405.0 NmReference

Torque RPM1500Reference

Transmission

16-speed mechanical shuttleReference

Typemechanical shuttleReference

Gears16 forward and reverseReference

Clutchdry discReference

PTO & Hydraulics

Pressure200.0 barReference

Total flow60.9 lpmReference

Rear TypeIIReference

Rear TypeIIIReference

Rear lift8681 kgReference

Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Engine RPM644@2350Reference

Engine RPM1105@2350Reference

Front PTOindependentReference

Front PTO Type540 (1.375)Reference

Engine RPM1036@2350Reference

Dimensions

Wheelbase274 cmReference

Weight5316 kgReference

Front tire16.9-28Reference

Rear tire18.4-38Reference

Ag front16.9-28Reference

Ag rear18.4-38Reference

Length496 cmReference

Width205 cmReference

Height (cab)290 cmReference

Clearance (front axle)50 cmReference

Clearance (rear axle)54 cmReference

Front tread160 to 199 cmReference

Rear tread139 to 199 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
