Tractor · 1981Unverified

Renault 145-14 TX

Name: Renault 145-14 TX
Brand: Renault

Renault 145-14 TX — TX Series · 128 hp. Reference specifications; pending source verification.

The Renault 145-14 TX is a tractor with a rated output of 128 hp, positioning it among the higher-powered machines in its class. Produced between 1981 and 1986, this model features a 6-cylinder turbocharged diesel liquid-cooled engine, which drives through four-wheel drive via a 12-speed gearbox. The listed weight is 6060 kg, and it is designed for use on areas of approximately 200–800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

128 hp

Weight

6060 kg

Catalogue coverage

Variants represented

Richest spec table

57 rows

Recorded power

128 hp

Recorded weight

6060 kg

Transmissions

12-speed synchronized

Production years

1981-1986

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerRenaultReference

Row-Crop tractorReference

Four-wheel driveReference

Power steeringReference

Hydraulic dry disc brakesReference

Cab standard with heat.Reference

Engine

MWM 6.2L 6-cyl dieselReference

Fuel tank199.8 LReference

Engine99.0 kWReference

MWM TD228-6Reference

turbocharged dieselReference

6-cylinderReference

liquid-cooledReference

Displacement6.2 LReference

Bore/Stroke105 x 120 mmReference

Power99.0 kWReference

Air cleanerdryReference

Rated RPM2350Reference

Torque482.1 NmReference

Torque RPM1500Reference

Starter volts12Reference

Transmission

12-speed synchronizedReference

16-speed creeperReference

TypesynchronizedReference

Gears12 forward and reverseReference

Clutch330mm cerametallic discReference

TypecreeperReference

Gears16 forward and reverseReference

PTO & Hydraulics

PTO (claimed)95.1 kWReference

Pressure180.0 barReference

Total flow41.6 lpmReference

Rear TypeIIReference

Controlposition and draft controlReference

Rear lift5292 kgReference

Rear PTOindependentReference

ClutchcerametallicReference

Rear PTO Type540/1000 (1.375)Reference

Engine RPM644@2350Reference

Engine RPM1105@2350Reference

Dimensions

Wheelbase274 cmReference

Weight6060 kgReference

Front tire16.9-28Reference

Rear tire18.4-38Reference

Standard tires (ag)Front: 16.9-28. Rear: 18.4-38Reference

Length508 cmReference

Width205 cmReference

Height292 cmReference

Max weight8500 kgReference

Clearance (front axle)53 cmReference

Clearance (rear axle)56 cmReference

Front tread160 to 199 cmReference

Rear tread150 to 199 cmReference

Electrical

Charging amps70Reference

Batteries2Reference

Battery volts12Reference

Battery AH150Reference

Speeds

With 18.4-38 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
