Tractor · 1980Unverified
Renault 461S
Renault 461S — S Series · 46 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
46 hp
Weight
4343 to 5081 pounds
Hover a source tag to verify
Overview
ManufacturerRenaultReference
Utility tractorReference
Two-wheel driveReference
Power steeringReference
Dry disc brakesReference
ROPS. Cab optional.Reference
Engine
MWM 2.8L 3-cyl dieselReference
Fuel tank65.1 LReference
Engine34.3 kWReference
MWM D327-3Reference
dieselReference
3-cylinderReference
air-cooledReference
Displacement2.8 LReference
Bore/Stroke98 x 120 mmReference
Power34.3 kWReference
Compression17.6:1Reference
Rated RPM2150Reference
Torque175.1 NmReference
Torque RPM1500Reference
Starter volts12Reference
Transmission
10-speedReference
Gears10 forward and 2 reverseReference
Clutchdry discReference
PTO & Hydraulics
Typeopen centerReference
Pressure180.0 barReference
Total flow24.6 lpmReference
Rear TypeIReference
Rear lift2500 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM524@2150Reference
Engine RPM734@2150Reference
Dimensions
Wheelbase210 cmReference
Weight4343 to 5081 poundsReference
Front tire6.00-16Reference
Rear tire13.6-28Reference
Ag front6.00-16Reference
Ag rear13.6-28Reference
Ag front6.50-16Reference
Ag front7.50-16Reference
Ag rear14.9-28Reference
Ag rear12.4-32Reference
Ag rear9.5-36Reference
Ag rear11.2-36Reference
Ag rear12.4-36Reference
Length344 cmReference
Width169 cmReference
Height (steering wheel)159 cmReference
Height (cab)235 cmReference
ROPS Weight1969 kgReference
Cab Weight2304 kgReference
Front tread119 to 189 cmReference
Rear tread130 to 180 cmReference
Electrical
Charging systemalternatorReference
Charging amps35Reference
Battery volts12Reference
Battery AH80Reference
Speeds
With 13.6-28 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
