Tractor · 1980Unverified

Renault 461S

Name: Renault 461S
Brand: Renault

Renault 461S — S Series · 46 hp. Reference specifications; pending source verification.

The Renault 461S is a compact tractor with a rated output of 46 hp. Produced from 1980 to 1987, this model features a 3-cylinder diesel air-cooled engine and a two-wheel drive system with a 10-speed gearbox. Weights for the Renault 461S range from 4343 to 5081 pounds. The 461S is designed for tasks on land areas of approximately 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

46 hp

Weight

4343 to 5081 pounds

Catalogue coverage

Variants represented

Richest spec table

59 rows

Recorded power

46 hp

Recorded weight

1969 kg

Transmissions

10-speed

Production years

1980-1987

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerRenaultReference

Utility tractorReference

Two-wheel driveReference

Power steeringReference

Dry disc brakesReference

ROPS. Cab optional.Reference

Engine

MWM 2.8L 3-cyl dieselReference

Fuel tank65.1 LReference

Engine34.3 kWReference

MWM D327-3Reference

dieselReference

3-cylinderReference

air-cooledReference

Displacement2.8 LReference

Bore/Stroke98 x 120 mmReference

Power34.3 kWReference

Compression17.6:1Reference

Rated RPM2150Reference

Torque175.1 NmReference

Torque RPM1500Reference

Starter volts12Reference

Transmission

10-speedReference

Gears10 forward and 2 reverseReference

Clutchdry discReference

PTO & Hydraulics

Typeopen centerReference

Pressure180.0 barReference

Total flow24.6 lpmReference

Rear TypeIReference

Rear lift2500 kgReference

Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Engine RPM524@2150Reference

Engine RPM734@2150Reference

Dimensions

Wheelbase210 cmReference

Weight4343 to 5081 poundsReference

Front tire6.00-16Reference

Rear tire13.6-28Reference

Ag front6.00-16Reference

Ag rear13.6-28Reference

Ag front6.50-16Reference

Ag front7.50-16Reference

Ag rear14.9-28Reference

Ag rear12.4-32Reference

Ag rear9.5-36Reference

Ag rear11.2-36Reference

Ag rear12.4-36Reference

Length344 cmReference

Width169 cmReference

Height (steering wheel)159 cmReference

Height (cab)235 cmReference

ROPS Weight1969 kgReference

Cab Weight2304 kgReference

Front tread119 to 189 cmReference

Rear tread130 to 180 cmReference

Electrical

Charging systemalternatorReference

Charging amps35Reference

Battery volts12Reference

Battery AH80Reference

Speeds

With 13.6-28 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
