The Renault 501 is a tractor with a rated power of 45 hp, categorising it as a lighter model within its class. It was manufactured from 1982 to 1986. The tractor is equipped with a 3-cylinder diesel liquid-cooled engine, paired with four-wheel drive and a 12-speed gearbox. Its operating weight is listed at 2239 kg, suitable for operations covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
45 hp
Weight
2239 kg
Catalogue coverage
Variants represented
2
Richest spec table
52 rows
Recorded power
45 hp
Recorded weight
2239 kg
Transmissions
12-speed gear
Production years
1982-1986
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
DistributorRenaultReference
ManufacturerCarraroReference
Utility tractorReference
Built in ItalyReference
Four-wheel driveReference
Power steeringReference
Mechanical disc brakesReference
Four-post ROPS.Reference
Engine
Perkins 2.5L 3-cyl dieselReference
Fuel tank60.0 LReference
Engine36.8 kWReference
Perkins 3.152Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.5 LReference
Bore/Stroke91 x 127 mmReference
Power36.8 kWReference
Rated RPM2200Reference
Torque172.2 NmReference
Torque RPM1350Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed gearReference
TypegearReference
Gears12 forward and 4 reverseReference
Clutchdry discReference
PTO & Hydraulics
PTO (claimed)33.6 kWReference
Pressure180.0 barReference
Pump flow22.3 lpmReference
Rear TypeIIReference
Rear lift1850 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2014Reference
Dimensions
Wheelbase205 cmReference
Weight2239 kgReference
Front tire9.5-20Reference
Rear tire13.6-28Reference
Standard tires (ag)Front: 9.5-20. Rear: 13.6-28Reference
Length338 cmReference
Width169 cmReference
Height (ROPS)225 cmReference
Ground clearance36 cmReference
Front tread140 to 157 cmReference
Rear tread133 to 172 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps28Reference
Battery volts12Reference
Battery AH100Reference
Speeds
With 13.6-28 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
