Tractor · 1982Unverified
Renault 601
Renault 601 — Utility tractor · 56 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
56 hp
Weight
2449 kg
Hover a source tag to verify
Overview
DistributorRenaultReference
ManufacturerCarraroReference
Utility tractorReference
Built in ItalyReference
Two- or four-wheel driveReference
Power steeringReference
Mechanical disc brakesReference
Four-post ROPS.Reference
Variants
601-22WDReference
601-44WDReference
Engine
Perkins 3.3L 4-cyl dieselReference
Fuel tank60.0 LReference
Engine44.2 kWReference
Perkins 4.204Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.3 LReference
Bore/Stroke91 x 127 mmReference
Power44.2 kWReference
Rated RPM2200Reference
Torque223.7 NmReference
Torque RPM1300Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed gearReference
TypegearReference
Gears12 forward and 4 reverseReference
Clutchdry discReference
PTO & Hydraulics
PTO (claimed)41.7 kWReference
Pressure180.0 barReference
Pump flow28.0 lpmReference
Rear TypeIIReference
Rear lift2702 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2014Reference
Dimensions
Wheelbase212 cmReference
Weight2449 kgReference
Front tire11.2-24Reference
Rear tire16.9-28Reference
Standard tires (ag)Front: 11.2-24. Rear: 16.9-28Reference
Length354 cmReference
Width178 cmReference
Height (ROPS)235 cmReference
Ground clearance40 cmReference
Front tread150 cmReference
Rear tread136 to 194 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps28Reference
Battery volts12Reference
Battery AH100Reference
Speeds
With 16.9-28 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
