Tractor · 1979Unverified
Renault 681
Renault 681 · 68 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
68 hp
Weight
7221 to 7464 pounds
Hover a source tag to verify
Overview
ManufacturerRenaultReference
Drive4x2 2WDReference
Drive4x4 MFWD 4WD optionalReference
Steeringhydrostatic powerReference
Dry disc brakesReference
standardReference
Engine
MWM 3.8L 4-cyl dieselReference
Fuel tank82.1 LReference
Engine50.7 kWReference
MWM D227-4Reference
dieselReference
4-cylinderReference
Displacement3.8 LReference
Bore/Stroke98 x 120 mmReference
Power50.7 kWReference
Rated RPM2350Reference
Torque230.0 NmReference
Torque RPM1500Reference
Transmission
12-speedReference
Gears12 forward and reverseReference
PTO & Hydraulics
Total flow30.3 lpmReference
Rear lift3850 kgReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase241 cmReference
Weight7221 to 7464 poundsReference
Front tire7.50-18Reference
Rear tire16.9-30Reference
Ag front7.50-18Reference
Ag rear16.9-30Reference
Ag front11.2-24Reference
Length404 cmReference
Height250 cmReference
Weight3275 kgReference
Weight3385 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
