Tractor · 1989Unverified
Renault 75-34 TX
Renault 75-34 TX — TX Series · 70 hp. Reference specifications; pending source verification.
The Renault 75-34 TX is a tractor with a rated power output of 70 hp, a mid-range figure for its class. This model was produced from 1989 to 1993. The tractor is equipped with a 4-cylinder diesel liquid-cooled engine and a four-wheel drive system featuring a hydrostatic transmission. Its operating weight is listed at 3840 kg, with a suitability for operations covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
70 hp
Weight
3840 kg
Catalogue coverage
Variants represented
2
Richest spec table
34 rows
Recorded power
70 hp
Recorded weight
3840 kg
Transmissions
12-speed
Production years
1989-1993
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerRenaultReference
Utility tractorReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Cab standardReference
Variants
75-322WDReference
75-344WDReference
Engine
MWM 4.2L 4-cyl dieselReference
Fuel tank120.0 LReference
Engine52.2 kWReference
MWM D226-4Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.2 LReference
Bore/Stroke105 x 120 mmReference
Power52.2 kWReference
Rated RPM2350Reference
Torque240.0 NmReference
Torque RPM1500Reference
Transmission
12-speedReference
Gears12 forward and reverseReference
PTO & Hydraulics
Total flow40.1 lpmReference
Rear lift3750 kgReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase240 cmReference
Weight3840 kgReference
Front tire13.6-24Reference
Rear tire16.9-34Reference
Ag front13.6-24Reference
Ag rear16.9-34Reference
Length404 cmReference
Height277 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
