Tractor · 1986Unverified

Renault 77-12 TS

Name: Renault 77-12 TS
Brand: Renault

Renault 77-12 TS · 70 hp. Reference specifications; pending source verification.

The Renault 77-12 TS is a tractor with a 70 hp rating, placing it in the middle of its class in terms of power output. Manufactured between 1986 and 1989, this model features a 4-cylinder diesel engine, which powers a four-wheel drive system with a hydrostatic transmission. The tractor's listed weight is 3405 kg, and it is designed to handle tasks on areas of around 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

70 hp

Weight

3405 kg

Catalogue coverage

Variants represented

Richest spec table

31 rows

Recorded power

70 hp

Recorded weight

3405 kg

Transmissions

12-speed

Production years

1986-1989

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerRenaultReference

Two-wheel driveReference

Steeringhydrostatic powerReference

Dry disc brakesReference

standardReference

Variants

77-144WDReference

Engine

MWM 4.2L 4-cyl dieselReference

Fuel tank107.9 LReference

Engine52.2 kWReference

MWM D226-4Reference

dieselReference

4-cylinderReference

Displacement4.2 LReference

Bore/Stroke105 x 120 mmReference

Power52.2 kWReference

Rated RPM2350Reference

Torque240.0 NmReference

Torque RPM1500Reference

Transmission

12-speedReference

Gears12 forward and reverseReference

PTO & Hydraulics

Total flow41.6 lpmReference

Rear lift3750 kgReference

Rear PTO Type540/1000Reference

Dimensions

Wheelbase239 cmReference

Weight3405 kgReference

Front tire7.50-18Reference

Rear tire16.9-34Reference

Ag front7.50-18Reference

Ag rear16.9-34Reference

Length404 cmReference

Height277 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
