Tractor · 1980Unverified
Renault 781S
Renault 781S · 78 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
78 hp
Weight
7056 to 8743 pounds
Hover a source tag to verify
Overview
ManufacturerRenaultReference
Drive4x2 2WDReference
Drive4x4 MFWD 4WD optionalReference
Steeringhydrostatic powerReference
Dry disc brakesReference
standardReference
Engine
MWM 4.2L 4-cyl dieselReference
Fuel tank76.8 LReference
Engine58.2 kWReference
MWM D226-4Reference
dieselReference
4-cylinderReference
Displacement4.2 LReference
Bore/Stroke105 x 120 mmReference
Power58.2 kWReference
Rated RPM2350Reference
Torque270.1 NmReference
Torque RPM1500Reference
Transmission
12-speedReference
Gears12 forward and reverseReference
PTO & Hydraulics
Total flow32.9 lpmReference
Rear lift4501 kgReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase242 cmReference
Weight7056 to 8743 poundsReference
Front tire7.50-18Reference
Rear tire16.9-34Reference
Ag front7.50-18Reference
Ag rear16.9-34Reference
Ag front13.6-24Reference
Length411 cmReference
Height263 cmReference
Weight3200 kgReference
Weight3965 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
