Tractor · 1996Unverified

Renault Ares 620

Name: Renault Ares 620
Brand: Renault

Renault Ares 620 — Ares Series · 110 hp. Reference specifications; pending source verification.

The Renault Ares 620 is a tractor model with a rated output of 110 hp, positioning it in the middle of its class in terms of power. Produced from 1996 to 2001, the Ares 620 features a 6-cylinder diesel liquid-cooled engine, which powers a four-wheel drive system through a hydrostatic transmission. Its listed weight is 5390 kg, and it is suited to tasks of approximately 200–800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

110 hp

Weight

5390 kg

Catalogue coverage

Variants represented

Richest spec table

32 rows

Recorded power

110 hp

Recorded weight

5390 kg

Transmissions

32-speed

Production years

1996-2001

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerRenaultReference

Four-wheel driveReference

Steeringhydrostatic powerReference

Wet disc brakesReference

cab with air conditioningReference

Engine

John Deere 6.8L 6-cyl dieselReference

Fuel tank180.2 LReference

Fuel tank219.9 LReference

Engine82.0 kWReference

John Deere 6068 DRTReference

dieselReference

6-cylinderReference

liquid-cooledReference

Displacement6.8 LReference

Bore/Stroke107 x 127 mmReference

Power82.0 kWReference

Rated RPM2200Reference

Torque450.1 NmReference

Torque RPM1500Reference

Transmission

32-speedReference

Gears32 forward and reverseReference

PTO & Hydraulics

Total flow60.2 lpmReference

Rear lift8331 kgReference

Rear PTO Type540/1000Reference

Dimensions

Wheelbase275 cmReference

Weight5390 kgReference

Front tire14.9R28Reference

Rear tire18.4R38Reference

Ag front14.9R28Reference

Ag rear18.4R38Reference

Length430 cmReference

Height291 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
