Tractor · 2001Unverified
Renault Ceres 335
Renault Ceres 335 — Ceres Series · 77 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
77 hp
Weight
8290 to 8952 pounds
Hover a source tag to verify
Overview
ManufacturerRenaultReference
Drive4x2 2WDReference
Drive4x4 MFWD 4WD optionalReference
Steeringhydrostatic powerReference
Wet disc brakesReference
cab standardReference
Engine
John Deere 4.5L 4-cyl dieselReference
Fuel tank145.0 LReference
Engine57.4 kWReference
John Deere 4045 DRTReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.5 LReference
Bore/Stroke107 x 127 mmReference
Power57.4 kWReference
Rated RPM2350Reference
Torque307.0 NmReference
Torque RPM1200Reference
Transmission
18-speedReference
20-speedReference
Gears18 forward and reverseReference
Gears20 forward and reverseReference
PTO & Hydraulics
Total flow51.9 lpmReference
Rear lift4109 kgReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase246 cmReference
Wheelbase243 cmReference
Weight8290 to 8952 poundsReference
Front tire7.50-18Reference
Rear tire16.9R34Reference
Ag front7.50-18 (2WD)Reference
Ag front13.6R24 (4WD)Reference
Ag rear16.9R34Reference
Length448 cmReference
Height249 cmReference
Weight3760 kgReference
Weight4060 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
