Tractor · 1965Unverified
Renault Super 3D
Renault Super 3D — Super D Series · 24 hp. Reference specifications; pending source verification.
The Renault Super 3D is a 24 hp tractor, classified as a lighter model within its range. It was manufactured from 1965 to 1968. The tractor features a 2-cylinder diesel air-cooled engine, coupled with two-wheel drive and a 10-speed gearbox. Its operating weight is 1770 kg, and it is suitable for operations covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
24 hp
Weight
1770 kg
Catalogue coverage
Variants represented
2
Richest spec table
40 rows
Recorded power
24 hp
Recorded weight
1770 kg
Transmissions
10-speed gear
Production years
1965-1968
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerRenaultReference
Built in Le Mans, FranceReference
Two-wheel driveReference
Manual steeringReference
Drum brakesReference
Open operator station.Reference
Engine
MWM 1.8L 2-cyl dieselReference
Fuel tank40.1 LReference
Engine17.9 kWReference
MWM D322-2Reference
dieselReference
2-cylinderReference
air-cooled inlineReference
Displacement1.8 LReference
Bore/Stroke98 x 120 mmReference
Power17.9 kWReference
Rated RPM2000Reference
Starter typeelectricReference
Oil capacity5.0 LReference
Transmission
10-speed gearReference
TypegearReference
Gears10 forward and 2 reverseReference
PTO & Hydraulics
Total flow18.2 lpmReference
Rear lift1350 kgReference
Rear PTOliveReference
Rear PTO Type540Reference
Dimensions
Wheelbase172 cmReference
Weight1770 kgReference
Front tire5.50-16Reference
Rear tire11-28Reference
Ag front5.50-16Reference
Ag rear11-28Reference
Ag front6.00-16Reference
Ag rear10-28Reference
Ag rear9-32Reference
Length316 cmReference
Width151 cmReference
Height (steering wheel)156 cmReference
Height (cab)221 cmReference
Ground clearance38 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
