Tractor · 1962Unverified
Renault Super 5
Renault Super 5 — Super Series · 35 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
35 hp
Hover a source tag to verify
Overview
ManufacturerRenaultReference
Utility tractorReference
Two-wheel driveReference
SteeringmechanicalReference
Drum brakesReference
Engine
Renault 2.3L 3-cyl dieselReference
Fuel tank40.1 LReference
Engine26.1 kWReference
Renault 592-30 AlfaReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.3 LReference
Bore/Stroke98 x 98 mmReference
Power26.1 kWReference
Rated RPM2000Reference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 1 reverseReference
PTO & Hydraulics
Total flow17.0 lpmReference
Rear PTO Type540/groundReference
Dimensions
Wheelbase175 cmReference
Front tire5.50-16Reference
Rear tire11.2-28Reference
Ag front5.50-16Reference
Ag rear11.2-28Reference
Length312 cmReference
Height153 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
