Tractor · 1995Unverified
Rhino 1210
Rhino 1210 — Compact Utility tractor · 16 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
16 hp
Weight
1070 kg
Hover a source tag to verify
Overview
ManufacturerRhinoReference
Compact Utility tractorReference
Built in ChinaReference
Two-wheel driveReference
Power steeringReference
Mechanical drum brakesReference
Two-post fixed ROPS.Reference
Variants
12102WDReference
Engine
0.9L 1-cyl dieselReference
Fuel tank21.2 LReference
Engine13.4 kWReference
dieselReference
1-cylinderReference
Displacement0.9 LReference
Power13.4 kWReference
Rated RPM2300Reference
Starter volts12Reference
Transmission
12-speed gearReference
TypegearReference
Gears12 forward and 4 reverseReference
Clutch228.6mm dry discReference
PTO & Hydraulics
PTO (claimed)11.9 kWReference
Typeopen centerReference
Pump flow24.2 lpmReference
Steering flow14.0 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift (at 24"/610mm)544 kgReference
Rear PTOliveReference
Rear PTO Type540 (1.375)Reference
Dimensions
Wheelbase128 cmReference
Weight1070 kgReference
Front tire4.0x14Reference
Rear tire8.3x20Reference
Standard tires (ag)Front: 4.0x14. Rear: 8.3x20Reference
Length228 cmReference
Width128 cmReference
Height (ROPS)204 cmReference
Clearance (front axle)25 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
